2.10.1
Configuration Data
The following example demonstrates how to use a Get function to obtain the configuration of a data
point on the Data Server (Dp_Cfg) using the unique <UCPTname> of the data point.
Request Message
<?xml version='1.0' encoding='utf-8'?>
<SOAP-ENV:Envelope SOAP-ENV:encodingStyle="http://schemas.xmlsoap.org/soap/encoding/"
xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">
<SOAP-ENV:Header>
<p:messageProperties xmlns:p="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">
<p:UCPTtimeStamp>2008-04-08T11:37:32.156-07:00</p:UCPTtimeStamp>
<p:UCPTuniqueId>0300000A5BF2</p:UCPTuniqueId>
<p:UCPTipAddress>10.2.124.53</p:UCPTipAddress>
<p:UCPTport>80</p:UCPTport>
<p:UCPTlastUpdate>2008-04-08T18:22:52Z</p:UCPTlastUpdate>
<p:UCPTprocessingTime>20</p:UCPTprocessingTime>
</p:messageProperties></SOAP-ENV:Header>
<SOAP-ENV:Body>
<Get xmlns="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">
<iLonItem>
<Item xsi:type="Dp_Cfg">
<UCPTname>Net/LON/iLON App/VirtFb/nviSwitch_3</UCPTname>
</Item>
</iLonItem>
</Get>
</SOAP-ENV:Body>
</SOAP-ENV:Envelope>
Response Message
<?xml version="1.0" encoding="utf-8" ?>
<SOAP-ENV:Envelope SOAP-ENV:encodingStyle="http://schemas.xmlsoap.org/soap/encoding/"
xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:xsd="http://www.w3.org/2001/XMLSchema"><SOAP-ENV:Header>
<p:messageProperties xmlns:p="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">
<p:UCPTtimeStamp>2008-04-08T11:56:41.116-07:00</p:UCPTtimeStamp>
<p:UCPTuniqueId>0300000A5BF2</p:UCPTuniqueId>
<p:UCPTipAddress>10.2.124.53</p:UCPTipAddress>
<p:UCPTport>80</p:UCPTport>
<p:UCPTlastUpdate>2008-04-08T18:22:52Z</p:UCPTlastUpdate>
<p:UCPTprocessingTime>46</p:UCPTprocessingTime>
</p:messageProperties>
</SOAP-ENV:Header>
<SOAP-ENV:Body>
<GetResponse xmlns="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">
<iLonItem >
<UCPTfaultCount>0</UCPTfaultCount>
<Item xsi:type="Dp_Cfg" >
<UCPTname>Net/LON/iLON App/VirtFb/nviSwitch_3</UCPTname>
<UCPTannotation>Dp_In;xsi:type="LON_Dp_Cfg"</UCPTannotation>
<UCPThidden>0</UCPThidden>
<UCPTlastUpdate>2008-03-26T16:16:43.070-07:00</UCPTlastUpdate>
<UCPTformatDescription>#0000000000000000[0].SNVT_switch</UCPTformatDescription>
<UCPTlength>2</UCPTlength>
<UCPTdirection LonFormat="UCPTdirection" >DIR_IN</UCPTdirection>
<UCPTunit field="" >value, state</UCPTunit>
<UCPTunit field="value" >% of full level</UCPTunit>
<UCPTunit field="state" >state code</UCPTunit>
<UCPTbaseType LonFormat="UCPTbaseType" >BT_STRUCT</UCPTbaseType>
<UCPTmaxFields>2</UCPTmaxFields>
<SCPTmaxSendTime>0.0</SCPTmaxSendTime>
<SCPTminSendTime>0.0</SCPTminSendTime>
<SCPTmaxRcvTime>0.0</SCPTmaxRcvTime>
<ValueDef>
<UCPTindex>0</UCPTindex>
<UCPTname>OFF</UCPTname>
<UCPTvalue LonFormat="#0000000000000000[0].SNVT_switch" >0.0 0</UCPTvalue>
