i.LON SmartServer 2.0 Programmer’s Reference

16-6

16.2

M-Bus Devices

The following section describes how to use the List, Get, Set, and Delete functions on M-Bus devices.

16.2.1

Using the List Function on M-Bus Devices

You can use the List function to retrieve a list of M-Bus devices on the SmartServer. The List function

takes an <iLonItem> element that has an xSelect statement with an MBS_Device_Cfg type as its input,

as shown in the example below.

Request

<xSelect>//Item[@xsi:type="MBS_Device_Cfg"]</xSelect>

</iLonItem>

</List>

Response

<Item>

<UCPTname>Net/M-Bus Channel/M-Bus Device</UCPTname>

<UCPTannotation>App;xsi:type="MBS_Device_Cfg"</UCPTannotation>

</Item>

</iLonItem>

</List>

You could use the list of <Item> elements returned by this function as input for the Get function. The

Get function would then return the configuration of each device included in the list. The next section

describes the properties included in each of these elements.

16.2.2

Using the Get Function on M-Bus Devices

You can use the Get function to retrieve the configuration of an M-Bus device defined on the

SmartServer. The input parameters you supply to this function will include one or more <Item>

elements with an MBS_Device_Cfg type. Each <Item> element will include the <UCPTname> of

each device whose configuration is to be returned by this function, as shown in the example below.

Request

<UCPTname>Net/M-Bus Channel/M-Bus Device</UCPTname>

</Item>

</iLonItem>

</Get>

Response

<UCPTname>Net/M-Bus Channel/M-Bus Device</UCPTname>

<UCPTuri>MBS_Device_Cfg.htm</UCPTuri>
