i.LON SmartServer 2.0 Programmer’s Reference

15-7

15.2

Modbus Devices

The following section describes how to use the List, Get, Set, and Delete functions on Modbus devices.

15.2.1

Using the List Function on Modbus Devices

You can use the List function to retrieve a list of Modbus devices on the SmartServer. The List

function takes an <iLonItem> element that has an xSelect statement with a MOD_Device_Cfg type as

its input, as shown in the example below.

Request

<xSelect>//Item[@xsi:type="MOD_Device_Cfg"]</xSelect>

</iLonItem>

</List>

Response

<Item>

<UCPTname>Net/Modbus Channel/LAE_LCD15_1</UCPTname>

<UCPTannotation>App;xsi:type="MOD_Device_Cfg"</UCPTannotation>

</Item>

</iLonItem>

</List>

You could use the list of <Item> elements returned by this function as input for the Get function. The

Get function would then return the configuration of each device included in the list. The next section

describes the properties included in each of these elements.

15.2.2

Using the Get Function on Modbus Devices

You can use the Get function to retrieve the configuration of a Modbus device defined on the

SmartServer. The input parameters you supply to this function will include one or more <Item>

elements with a MOD_Device_Cfg type. Each <Item> element will include the <UCPTname> of each

device whose configuration is to be returned by this function, as shown in the example below.

Request

<UCPTname>Net/Modbus Channel/LAE_LCD15_1</UCPTname>

</Item>

</iLonItem>

</Get>

Response

<UCPTname>Net/Modbus Channel/LAE_LCD15_1</UCPTname>

<UCPTuri>MOD_Device_Cfg.htm</UCPTuri>

</Address>
