i.LON SmartServer 2.0 Programmer’s Reference

14-40

<Item>

<UCPTname> Building 2/Channel 1/DIO-5/Digital Counter[0]</UCPTname>

</Item>

</iLonItem>

</SetResponse>

14.6.4

Using the Delete Function on a LONWORKS Functional Block

You can use the Delete function to delete a functional block on the SmartServer, or in an LNS network

database via the LNS Proxy Web service. The Delete function takes an <Item> element with a

LON_Fb_Cfg type as its input. The <Item> element only needs to include the functional block’s

<UCPTname> property in the Delete Request as demonstrated in the following code sample:

Request

<UCPTname>MyOldNetwork/MyOldChannel/MyOldDevice/MyOldFb</UCPTname>

</Item>

</iLonItem>

</Delete>

Response

<Item>

<UCPTname>MyOldNetwork/MyOldChannel/MyOldDevice/MyOldFb</UCPTname>

</Item>

</iLonItem>

</Delete>

14.7

Network Variables (LONWORKS Data Points)

The following section describes how to use the List, Get, Set, and Delete functions on network

variables (L

ONWORKS data points). For information on reading and writing values to network

variables, see Chapter 4,

Using the SmartServer Data Server.

14.7.1

Using the List Function on Network Variables

You can use the List function to retrieve a list of network variables (LONWORKS data points) on the

SmartServer or to retrieve a list of network variables in a specific LNS network database via the LNS

Proxy Web service. The List function takes an <iLonItem> element that has an xSelect statement with

a LON_Dp_Cfg type as its input, as shown in the example below.

Request (return all the Network variables of all the functional blocks on the SmartServer or in

an LNS network database)

</iLonItem>

</List>

Alternatively, you can filter the network variables (LONWORKS data points) returned by the List

function to those on a specific functional block by including the <UCPTname>of the parent functional

block in the xSelect statement, or you can filter the network variables returned using the <UCPTname>

and <UCPTlastUpdate> data point properties.

Request (use an xSelect statement to return all the network variables on a specific functional

block)
