i.LON SmartServer 2.0 Programmer’s Reference
14-12
<Item>
<UCPTname>Net/LON IP</UCPTname>
<UCPTannotation>IP;xsi:type="LON_Channel_Cfg"</UCPTannotation>
<UCPThidden>1</UCPThidden>
</Item>
</iLonItem>
</List>
The List function returns a list of <Item> elements for each LONWORKS channel defined on the
SmartServer or each L
ONWORKS channel defined in a specific LNS network database.
You could use the list of <Item> elements returned by this function as input for the Get function. The
Get function would then return the configuration of each channel included in the list. The next section
describes the properties included in each of these elements.
14.2.2
Using the Get Function on a LONWORKS Channel
You can use the Get function to retrieve the configuration of a LONWORKS channel defined on the
SmartServer or a L
ONWORKS channel in a specific LNS network database. The input parameters you
supply to this function will include one or more <Item> elements with a LON_Channel_Cfg type.
Each <Item> element will include the <UCPTname> of each channel whose configuration is to be
returned by this function, as shown in the example below.
Request
<Get xmlns="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">
<iLonItem>
<Item xsi:type="LON_Channel_Cfg">
<UCPTname>Net/LON</UCPTname>
</Item>
</iLonItem>
</Get>
Response
<Get xmlns="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">
<iLonItem>
<UCPTfaultCount>0</UCPTfaultCount>
<Item xsi:type="LON_Channel_Cfg">
<UCPTname>Net/LON</UCPTname>
<UCPTannotation>TP;xsi:type="LON_Channel_Cfg"</UCPTannotation>
<UCPThidden>0</UCPThidden>
<UCPTlastUpdate>2008-03-20T17:42:54.903-07:00</UCPTlastUpdate>
<UCPTuri>LON_Channel_Cfg.htm</UCPTuri>
<UCPThandle>0</UCPThandle>
<UCPTchannelType LonFormat="UCPTchannelType">CT_LON</UCPTchannelType>
<UCPTtransceiverId LonFormat="UCPTtransceiverId">TP_FT_10</UCPTtransceiverId>
<UCPTtransmitTimer LonFormat="UCPTtransmitTimer">TT_96</UCPTtransmitTimer>
<UCPTretryCount>3</UCPTretryCount>
<UCPTmaxPriority>4</UCPTmaxPriority>
<UCPTchannelMode LonFormat="UCPTchannelMode">AM_ONLINE</UCPTchannelMode>
<UCPTdynamic LonFormat="UCPTdynamic">DDT_STATIC</UCPTdynamic>
</Item>
</iLonItem>
</Get>
The Get function returns an <Item> element for each channel referenced in the input parameters you
supplied to the function. The properties included within each <Item> element are initially defined
when the channel is added to the SmartServer or LNS network database. You can write to these
channel properties with the Set function. The following table describes these properties.
Property Description
<UCPTname>
The name of the channel in the following format:
<network/channel>. You can rename a L
ONWORKS channel by
providing its <UCPThandle> and specifying the new
