i.LON SmartServer 2.0 Programmer’s Reference
14-5
Property Description
<UCPTmgmtMode>
Specifies when network configuration changes are propagated
over the network to devices. This property can be one of the
following values:
• LCA_ONNET. Changes are sent immediately to the
devices on the network. Use LCA_ONNET if you are
installing an engineered network, or if you are designing
and installing an ad-hoc network at the same time.
• LCA_OFFNET. Changes are stored in the network
database and then sent to the devices on the network when
you place the SmartServer OnNet. Use LCA_OFFNET if
you are designing an engineered network.
<UCPTlnsNetworkInterface>
Specifies the network interface to be used for communication
between the LNS Server and the network. To specify that the
SmartServer is not attached to a network, you can omit this
property in a Set function. This may be desired if you are
performing network design tasks.
<UCPTdomain>
The domain length, index and key. If both the length and key
are provided in a Set function, but they don’t match, an error is
thrown.
14.1.3
Using the Set Function on a LONWORKS Network
You can use the Set function to overwrite the configuration of a network, or to create a new network.
The input parameters you supply to the function will include one or more <Item> elements. Each
<Item> element includes a <UCPTname> property (case-insensitive) that specifies a unique network to
be created or modified.
Each <Item> element may also include a series of properties that define the configuration of the new
(or modified) network. This set of properties is the same, whether you are creating a new network or
modifying an existing network. The previous section,
Using the Get Function on a LONWORKS
Network, details the properties you can include in the Set function.
You can set multiple networks with a single Set message. However, you should not attempt to create
or write to more than 100 networks with a single call to the Set function.
Request (using the SmartServer Web service, create a new network and set it to Standalone
mode)
<Set xmlns="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">
<iLonItem>
<Item xsi:type="LON_Network_Cfg">
<UCPTname>MyNewNetwork_1</UCPTname>
<UCPThandle xsi:type="number">873906929</UCPThandle>
<LnsDatabase>
<UCPTname>MyNewNetwork</UCPTname>
<UCPTservicePath xsi:type="string">//WebService[UCPTindex=4]</UCPTservicePath>
</LnsDatabase>
<UCPTlnsSync xsi:type="string" LonFormat="UCPTlnsSync">SYNC_STANDALONE</UCPTlnsSync>
<UCPTmgmtMode xsi:type="string" LonFormat="UCPTmgmtMode">LCA_ONNET</UCPTmgmtMode>
<UCPTlnsNetworkInterface>X.Default.SmartServer_RNI</UCPTlnsNetworkInterface>
</Item>
</iLonItem>
</Set>
Note: In the Set function, you need to specify the <UCPThandle> property of the current network on
the SmartServer. You can use the List and Get functions to get the network currently on the
