i.LON SmartServer 2.0 Programmer’s Reference
11-4
Property Description
<UCPTannotation>
The program ID and functional profile template used by the
real-time clock. This property is always
8000010128000000[4].UFPTrealTimeClock
<UCPThidden>
A flag indicating whether the real-time clock functional
block is hidden or shown in the navigation pane on the left
side of the SmartServer Web interface. This property may
have the following values:
0 – shown
1 – hidden
<UCPTitemStatus>
This property only appears if the data logger is not
synchronized with an LNS network database or it has been
deleted. In this case, it has the following values:
IS_NOTSYNCED
IS_DELETED
<UCPTlastUpdate>
A timestamp indicating the last time the configuration of the
real-time clock was updated. This timestamp uses the
following format:
YYYY-MM-DDTHH:MM:SSZ
<UCPTuri>
The name of the file containing the configuration web page
for the Real-Time Clock on the SmartServer flash disk,
absolute or relative to /web/user/echelon. This property is
#8000010128000000[4].UFPTrealTimeClock _Cfg.htm by
default.
<UCPTdegLongitude>
The north-south location of the SmartServer relative to the
equator as a decimal fraction. If the SmartServer is located
south of the equator, this is a negative value between 0 and
–90. If it is located north of the equator, it is a positive
value between 0 and 90.
<UCPTdegLatitude>
The east-west location of the SmartServer relative to the
Prime Meridian as a decimal fraction. If the SmartServer is
located west of the Prime Meridian, this is a negative value
between 0 and –180. If it is located is located east of the
Prime Meridian, it is a positive value between 0 and 180.
11.3.3
Using the Set Function on a Real-Time Clock
You can use the Set function to create new real-time clocks, or to overwrite the configuration of
existing real-time clocks. The real-time clocks to be created or written to are signified by a list of
<Item> elements in the input you supply to the function. The properties you must define within each
<Item
> element are the same, whether you are creating a new real-time clock or modifying an existing
real-time clock. The previous section,
Using the Get Function on a Real-Time Clock, describes these
properties.
Note: If you specify a real-time clock with the <UCPTname> element, the Set function deletes the
specified real-time clock before the specified parameters are set. If the <UCPTname> element is not
specified, a new real-time clock is created.
