i.LON SmartServer 2.0 Programmer’s Reference
10-9
Identifier Description
DM_FIFTH_FRI Fifth Friday of each month
DM_FIFTH_SAT Fifth Saturday of each month
DM_LAST_SUN Last Sunday of each month
DM_LAST_MON Last Monday of each month
DM_LAST_TUE Last Tuesday of each month
DM_LAST_WED Last Wednesday of each month
DM_LAST_THU Last Thursday of each month
DM_LAST_FRI Last Friday of each month
DM_LAST_SAT Last Saturday of each month
DM_EVERY_SUN Every Sunday of the date interval.
DM_EVERY_MON Every Monday of the date interval.
DM_EVERY_TUE Every Tuesday of the date interval.
DM_EVERY_WED Every Wednesday of the date interval.
DM_EVERY_THU Every Thursday of the date interval.
DM_EVERY_FRI Every Friday of the date interval.
DM_EVERY_SAT Every Saturday of date interval
DM_EVERY_SECOND_DAY Every second day of date interval
DM_EVERY_THIRD_DAY Every third day of date interval
DM_EVERY_FOURTH_DAY Every fourth day of the date interval
DM_EVERY_FIFTH_DAY Every fifth day of the date interval
DM_EVERY_SIXTH_DAY Every sixth day of the date interval
DM_NUL Value not available. If this is chosen, the Calendar will use
every day.
10.3.2.4 Monthly Recursions
The following table lists and describes the values you can specify in the <UCPTschedMonth> property
of the <UCPTSchedule> element. The calendar will be active during the months specified by this
property.
