i.LON SmartServer 2.0 Programmer’s Reference
8-10
8.3.2.2 Comparison Functions
The following table lists and describes the comparison functions you can use to fill in the
<UCPTcompFunction> property. You must reference each function by the identifier listed in the table.
Identifier Description
FN_GT
Greater than. Returns True if the value of the input data point is greater than
that of the compare data point (or the value assigned to the
<UCPTtrueThreshold> property, if it is defined).
FN_LT
Less than. Returns True if the value of the input data point is less than that
of the compare data point (or the value assigned to the
<UCPTtrueThreshold> property, if it is defined).
FN_GE
Greater than or equal to. Returns True if the value of the input data point is
greater than or equal to that of the compare data point (or the value assigned
to the <UCPTtrueThreshold> property, if it is defined).
FN_LE
Less than or equal to. Returns True if the value of the input data point is
less than or equal to that of the compare data point (or the value assigned to
the <UCPTtrueThreshold> property, if it is defined).
FN_EQ
Equal. Returns True if the value of the input data point is equal to that of
the compare data point (or the value assigned to the <UCPTtrueThreshold>
property, if it is defined).
FN_NE
Not equal. Returns True if the value of the input data point is not equal to
that of the compare data point (or the value assigned to the
<UCPTtrueThreshold> property, if it is defined).
FN_NUL
No comparison function is used. This is true if <UCPToutput Function> is
set to FN_MAX, FN_MIN, FN_SUM, or FN_AVERAGE.
8.3.2.2.1 FN_AND Example
In this example, there are four input data points and one compare data point, all of the type
SNVT_count. There is one output data point, of the type SNVT_switch.
<UCPToutputFunction>: FN_AND
<UCPTcompFunction>: FN_GT
Because the output function is FN_AND, the comparisons made with all the input data points must
return True for the output data point to be set to True. The comparison function is FN_GT, so the
value of each input data point must be greater than the value of the compare data point, or greater than
the value of the <UCPTtrueThreshold> value (if defined) for this to happen. If the
<UCPTtrueThreshold> property is defined, then the value of the compare data point is not used in the
comparison.
The following table lists several case scenarios that show when these functions might would evaluate
to True (100.0 1).
Input 1 Input 2 Input 3 Input 4 Value of Compare Data Point UCPTtrueThreshold Output
9 11 12 13 Does not matter since
<UCPTtrueThreshold> is defined.
10 0.0 0
20 30 40 50 Does not matter since
<UCPTtrueThreshold> is defined.
10 100.0 1
