i.LON SmartServer 2.0 Programmer’s Reference
8-8
Property Description
<SCPTovrValue>
The value the output data point will be assigned when it is
overridden, and the <SCPTovrBehave> property is set to
OV_SPECIFIED.
<UCPTpollOnResetDelay>
The delay, in seconds, the Analog Function Block wait after
a reset before polling the values of the input data points.
When this value is 0, the Analog Function Block will
resume polling the input data points at the rate specified by
the <UCPTpollRate> property after a reset.
This field has a range of 0.0-6553.0.
8.3.2.1 Output Functions
The following table lists and describes the output functions you can use to fill in the
<UCPToutputFunction> property. You must reference each function by the identifier listed in the
table. The function selected determines the value that the Analog Function Block will assign to the
output data point.
Identifier Value Assigned To The Output Data Point
FN_MAX
Maximum value of all input data points.
FN_MIN
Minimum value of all input data points.
FN_SUM
The sum of the values of all input data points.
FN_AVERAGE
The average of the values of the input data points.
FN_COMPARE
The result of the last comparison between the input data point(s) and the
compare data point (or the value assigned to the <UCPTtrueThreshold>
property, if it is defined). If this is selected, you must also select a comparison
function by filling in the <UCPTcompFunction> property. For an example of
how you could use this function, see the
FN_COMPARE Example section.
FN_AND
This function reports True when all the input data points are True. The
definition of a True input depends on the data point type. If the input type is
SNVT_switch, the input is True if the value and state fields are non-zero. If
the input type is a structure other than SNVT_switch, the Boolean threshold is
undefined, and FN_AND should not be used.
If the input data point(s) type is a scalar or enumeration value, the function
reports True if all the comparisons made by the comparison function for the
analog function block are True. For an example of how you could use the
FN_AND output function in this way, see the
FN_AND Example section.
FN_OR
This function reports True when any of the input data points are True. The
definition of a True input depends on the data point type. If the input type is
SNVT_switch, the input is True if either state or value field is non-zero. If the
input type is a structure other than SNVT_switch, the Boolean threshold is
undefined, and FN_OR should not be used.
If the input data point(s) type is a scalar or enumeration value, the function
reports True if any of the comparisons made by the comparison function for
