i.LON SmartServer 2.0 Programmer’s Reference
7-11
Property Description
<UCPTalarmPriority2>
The priority level to be assigned to the data point when it reaches
an alarm condition. This must be an integer between 0 (high
priority) and 255 (low priority). You can use priority levels to sort
the alarms with the summary log view, or with the SmartServer
Web pages. The default value is 0.
<UCPTdescription>
A user-defined description of the alarm condition for this data
point. This can be a maximum of 201 characters long.
7.3.2.2 E-mail Profiles
The following table describes the properties that you must define within each <Mail> element. As
described previously in this chapter, each <Mail> element defines an e-mail profile for the Alarm
Notifier.
<Mail>
<UCPTindex>0</UCPTindex>
<UCPTnickName>Alarm Notification </UCPTnickName>
<UCPTemailAddress>user@echelon.com</UCPTemailAddress>
<UCPTemailFormat>{status} {new_line}{alarm_time}</UCPTemailFormat>
<UCPTemailSubject>Data Logger at Alarm Level</UCPTemailSubject>
<UCPTemailAttachment/>
</Mail>
You will reference these e-mail profiles when creating the active and passive destinations for your
Alarm Notifier. An e-mail will be sent to the e-mail address specified for the profile each time any of
the destinations that reference the profile are used. For more information on the active and passive
alarm destination sets, see
Active and Passive Alarm Destinations.
Property Description
<UCPTindex>
The index number of the e-mail profile.
<UCPTNickName>
The name of the e-mail profile. You will use this name to
reference the e-mail profile when setting up active and passive
alarm destinations. The name can be a maximum of 31 characters
long.
<UCPTemailAddress>
The e-mail address for this profile. An e-mail will be sent to this
address each time the profile is used. The address can be a
maximum of 1024 characters long.
<UCPTemailFormat>
The message text e-mails sent by this profile will contain, as a
string. The SOAP interface provides a group of variable
substitutions that can be used to automatically insert information
about the alarm into the message. For example:
%al occurred at %dy / %dm/ %dd %pn and reached the level
of %va.
For a description of the variable substitutions you can use, see
the next section,
E-mail Variable Substitutions. This message
can be a maximum of 4096 characters long.
<UCPTemailSubject>
The subject of the e-mails sent for this profile. This can be a
maximum of 1024 characters long.
