Datasheet

DC centrifugal compact fan
single inlet
RLF 100-11/14
Technical features
Dimensions 127 x 127 x 25 mm
General description Pressure-optimized blower. Optional Vario-Pro: Highly flexible software configuration for the fan
ensures an easily customizable solution to meet the individual requirements of your application.
Backward curved impeller. Electronic commutation completely integrated.
Connection line Single strands AWG 22, TR 64, bared and tin-plated.
Locked-rotor protection Electronic blocking and overload protection.
Direction of protection Right, looking at rotor
Direction of air flow Axial air intake, centrifugal air exhaust out of the outlet.
Bearing Ball bearings
Lifetime L10 at 40 °C 80000 h
Lifetime L10 at maximum
temperature
30000 h
Mass 0.320 kg
Housing material Scroll housing of fiberglass-reinforced plastic, housing base of galvanized sheet steel.
Material of impeller Fiberglass-reinforced plastic
Motor protection Protected against reverse polarity and locking.
Option Alarm signal
Approval VDE, CSA, UL, CE
