Product Data Sheet RG160-28/14NU Product Data Sheet RG160-28/14NU The engineer's choice
Product Data Sheet RG160-28/14NU RG160-28/14NU INDEX 1 General ............................................................................................................................................................... 3 2 Mechanics .......................................................................................................................................................... 3 2.1 2.2 3 Operating Data ......................................................................................
Product Data Sheet RG160-28/14NU 1 General Fan type Rotating direction looking at rotor Airflow direction Bearing system Mounting position - shaft 2 Mechanics 2.1 General Blower Counterclockwise Air in axially, Air out radially Ball bearing Any Width Height Depth Mass Housing material Impeller material Max. torque when mounted across both mounting flanges; Metal flange on mounting plate Screw size 2.
Product Data Sheet RG160-28/14NU 3 Operating Data 3.1 Electrical Operating Data Measurement conditions: ∆p = 0: I: Normal air density = 1,2 kg/m3; Temperature 23°C +/ - 3°C; Motor axis horizontal; warm-up time before measuring 5 minutes (unless otherwise specified). In the intake and outlet area should not be any solid obstruction within 0,5 m. corresp. to free air flow (see chapter aerodynamics) corresp. to arithm.
Product Data Sheet RG160-28/14NU 01/31/2019 page 5 of 11
Product Data Sheet RG160-28/14NU 3.3 Aerodynamics Measurement conditions: Measured with a double chamber intake rig acc. to DIN EN ISO 5801. Normal air density = 1,2 kg/m3; Temperature 23°C +/ - 3°C; In the intake and outlet area should not be any solid obstruction within 0,5 m. Motor shaft horizontal. The information is only valid under the specified test conditions and may be changed by the installation conditions.
Product Data Sheet RG160-28/14NU 01/31/2019 page 7 of 11
Product Data Sheet RG160-28/14NU 3.4 Sound Data Measurement conditions: Sound pressure level: 1 meter distance between microphone and the air intake. Sound power level: Acc. to DIN 45635 part 38 (ISO 10302) Measured in a semianchoic chamber with a background noise level of Lp(A) < 5 dB(A) For further measurement conditions see chapter aerodynamics. a.) Operation condition: 2.
Product Data Sheet RG160-28/14NU Please require severity levels and specification parameters from the responsible development departments.
Product Data Sheet RG160-28/14NU 5 Safety 5.1 Electrical Safety Dielectric strength DIN EN 60950 (VDE 0805) and DIN EN 60335 (VDE 0700) A.) Type test Measuring conditions: After 48h of storage at 95% R.H. and 25°C. No arcing or breakdown is allowed! All connections together to ground. B.) Routine test Measuring conditions: At indoor climate. No arcing or breakdown is allowed! All connections together to ground. Isolation resistance Measuring conditions: After 48h of storage at 95% R.H.
