Datasheet

Product Data Sheet RET97-25/14/2TDP-052
02/01/2019 page 10 of 14
3.5 Aerodynamics
Measurement
conditions:
Measured with a double chamber intake rig acc. to DIN EN ISO 5801.
Normal air density = 1,2 kg/m3; Temperature 23°C +/ - 3°C;
In the intake and outlet area should not be any solid obstruction within 0,5 m. Motor shaft
horizontal.
The information is only valid under the specified test conditions and may be changed by the
installation conditions. If there are deviations from the standard test conditions, the
characteristic values must be checked under the installed conditions.
a.) Operation condition:
5.600 1/min at free air
flow
PWM 90 %;
Max. free-air flow (∆p = 0 / = max.) 208,0 m3/h
Max. static pressure (∆p = max. / =0) 810 Pa
The measurements were taken in the volute housing of G2S097-... The speed at free air is at 24 V approx.
5.700 1/min.
at free air flow
at free air flow
