CONTROL UNIT FOR EBERSPÄCHER PARKING HEATERS A WORLD OF COMFORT INSTALLATION INSTRUCTIONS QUICK START GUIDE O P E RAT IN G I N S T R U CTION S E A S Y S TA RT T I M E R EN OPERATING INSTRUCTIONS V E H I C L E H E AT E R S | T E C H N I C A L D O C U M E N TAT I O N
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION CO N T E N T S CHAPTER CHAPTER TITLE CHAPTER CONTENTS 1 2 3 PAGE INTRODUCTION Please read first 4 Safety information 4 Range of uses 4 General information 4 EU Declaration of conformity 4 OVERVIEW EasyStart Timer 5 Button functions 5 Longpress button 5 Shortpress button 5 Longpress button 5 Shortpress button 5 Press button 1x / keep pressed 5 Press button 1x / keep pressed 5 OPERATION AND SE
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 3 CO N T E N T S 4 HEATING Off with Shortpress 12 Change the temperature setpoint and / or the operating time during operation 12 Set VENTILATION ON with Shortpress and if applicable set the operating time 14 VENTILATION OFF with Longpress 15 VENTILATION OFF with Shortpress 15 ADD-ON UNIT ON – e.g. activate the HEATING function for a 2nd heater 16 ADD-ON UNIT ON – e.g.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 1 I N T R O D U C T ION PLEASE READ FIRST Before you start to set and use the timer, always read through these operating instructions carefully. These operating instructions contain important information that you require for to set and use the timer. Please keep these operating instructions in a safe place for subsequent reference. GENERAL INFORMATION The EasyStart Timer has a simple operating structure.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 5 2 O V E R V IE W EASYSTART TIMER The EasyStart Timer can be used to make the necessary settings for operation of the heater and / or the add-on unit. BUTTON FUNCTIONS LONGPRESS button The button must be pressed for longer than 2 seconds. The heater is switched on immediately if ON or OFF appears in the display (except if programming is running or while making settings).
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 O PE R AT I O N A N D SETTIN G /AD J USTME NT NOTES ON OPERATION AND SETTING FLASHING SYMBOL / FLASHING VALUE ACTIVATING THE EASYSTART TIMER In the Main menu a flashing symbol in the Menu bar is activated with the button. If the display is not lit the EasyStart Timer must be activated (not if heating ON with LONGPRESS). SHORTPRESS on one of the four buttons, the Start display appears in the display, then continue with the operation or setting.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 7 3 Operation and setting /adjustment NOTES ON OPERATION AND SETTING FACTORY SETTING EXTENDING THE OPERATING TIME PROGRAM / PRESELECTION (for all heaters) The operating time can be extended to up to 720 min, the input is made from the 120th min. in 5 min intervals. To do this, contact the installation workshop.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 Operation and setting /adjustment MAIN MENU STATUS AREA If no menu item is activated, the current time and, if an (optional) temperature sensor is connected, the temperature in the vehicle interior are displayed in the status area. Start display: Time, e.g. 17:30 Temperature in the vehicle interior, e.g. 21 °C. Menu bar 17:30 21 °C Status area MENU BAR The following menu items can be selected.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 9 3 Operation and setting /adjustment START DISPLAY AFTER SWITCHING ON 17:30 21 °C If no menu item is activated, the Start display appears with a flashing heater symbol in the Menu bar, with the current time and the actual temperature in the status area. Other possible actions are: HEATING IMMEDIATELY with LONGPRESS. HEATING ON with SHORTPRESS, in addition confirm and if applicable set the temperature setpoint and operating time, see page 11.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 Operation and setting /adjustment HEATING IMMEDIATELY WITH LONGPRESS (WITHOUT SETTINGS) Press the LONGPRESS button for longer than 2 seconds. Heater ON. 30 min 21 °C Display for air heaters in continuous heating mode (factory setting). ∞ 21 °C PLEASE NOTE! After switching on, “On” is displayed for 2 sec and for air then the remaining operating time or heaters. Set values are copied from the previous heating mode.
08:30 120 min VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 11 3 Operation and setting /adjustment HEATING ON WITH SHORTPRESS AND WITH SETTINGS Display ON, the Start display appears. 17:30 Press the 2 seconds. SETTING THE OPERATING TIME or button to set the If necessary, use the operating time. Operating time setting range: Min 10 – max 120 min in 1 min. increments, continuous heating mode is possible for air heaters.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 Operation and setting /adjustment HEATING OFF WITH SHORTPRESS Display ON, the HEATING menu item is displayed. CHANGE THE TEMPERATURE SETPOINT AND / OR THE OPERATING TIME DURING OPERATION Press the Display ON, the HEATING / VENTILATION / ADD-ON SHORTPRESS button for less than UNIT HEATING or ADD-ON VENTILATION menu item is displayed. Press the SHORTPRESS button for less than 2 seconds. Heater Off. 2 seconds.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 13 3 Operation and setting /adjustment SETTING THE OPERATING TIME or button to set the operating time. Use the Operating time setting range: Min 10 – max 120 min in 1 min. increments, continuous heating mode is possible for air heaters. 60 min Press the button to confirm the operating time. The operating time is changed once. 60 min 21 °C Display for air heaters in continuous heating mode.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 Operation and setting /adjustment SET VENTILATION ON WITH SHORTPRESS AND IF APPLICABLE SET THE OPERATING TIME Display ON, the Start display appears. Use the or button to select the ventila- tion symbol in the Menu bar. 21 °C Off Confirm the VENTILATION menu item by pressing the button. PLEASE NOTE! The following setting or confirmation is absolutely necessary. SETTING THE OPERATING TIME or button to set the If necessary, use the operating time.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 15 3 Operation and setting /adjustment VENTILATION OFF WITH LONGPRESS VENTILATION OFF WITH SHORTPRESS Display ON, the VENTILATION menu item is displayed. Display ON, the VENTILATION menu item is displayed. Press the Press the LONGPRESS button for longer than 2 seconds 2 seconds. Heater OFF. Heater OFF. 21 °C Off After the VENTILATION OFF display the Start display appears.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 Operation and setting /adjustment ADD-ON UNIT ON – E.G. ACTIVATE THE HEATING FUNCTION FOR A 2ND HEATER Display ON, the Start display appears. Use the or in the Menu bar. Off button to select the 21 °C symbol 08:30 120 min Confirm the ADD-ON UNIT menu item by pressing the button. Use the or button to select the symbol. SET TEMPERATURE SETPOINT – FOR AIR HEATERS ONLY Use the or button to set the temperature setpoint.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 17 3 Operation and setting /adjustment Display for air heaters in continuous heating mode (factory setting). ADD-ON UNIT ON – E.G. ACTIVATE THE VENTILATION FUNCTION FOR A 2ND HEATER Display ON, the Start display appears. Use the ∞ PLEASE NOTE! After switching on, “On” is displayed for 2 sec and for air then the remaining operating time or heaters. During heating mode it is possible to switch to another menu item.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 Operation and setting /adjustment SETTING THE OPERATING TIME Use the or button to set the operating time. Operating time setting range: Min 10 – max 120 min in 1 min. increments, continuous VENTILATION mode possible for air heaters. 60 min Press the button to confirm the operating time. The operating time is changed permanently. Heater ON.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 19 3 Operation and setting /adjustment ADD-ON UNIT OFF WITH LONGPRESS ADD-ON UNIT OFF WITH SHORTPRESS Press the Display ON, the ADD-ON UNIT – HEATING menu item is displayed. LONGPRESS button for longer than 2 seconds Press the Add-on unit OFF. SHORTPRESS button for less than 2 seconds. Add-on unit OFF. Off 21 °C After the ADD-ON UNIT OFF display the Start display appears. If the vehicle lighting is OFF the display lighting goes out after 10 seconds.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 Operation and setting /adjustment GENERAL INFORMATION ON PROGRAMMING THE PRESET TIME The programming of the preset time is carried out in menu item . The EasyStart Timer can be used to program 3 preset times. The 3 preset times can either all take place on one weekday or can be distributed between different weekdays. 3 weekday ranges are available to choose from, these can each be started daily with a preset time.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 21 3 Operation and setting /adjustment AUTOMATIC OPERATING TIME CALCULATION (for water heaters only) For water heaters and a temperature sensor connected to the EasyStart Timer the heating start is calculated automatically depending on the measured room temperature and the selected heating level (ECO or HIGH). The operating time can lie between 10 and 60 minutes; operation is always ended 5 minutes after the programmed departure time.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 Operation and setting /adjustment PROGRAM PRESET TIMES Program memory P1 display, factory setting. Display ON, the Start display appears. Use the or the Menu bar. button to select the 1 symbol in Display, if no preselection is activated. Mo. - Fr. 21 °C 07 : 00 30 min. Program memory P2 display with programmed preselection. 1 2 3 Display, if a preselection is activated e.g. P2. 1 2 3 2 Mi. 21 °C 06 : 30 60 min.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 23 3 Operation and setting /adjustment SELECTING THE WEEKDAY GROUP / WEEKDAY 2 Use the or button to select the weekday group Mon – Fri, Sat – Sun, Mon – Sun or a weekday Mon, Tue, Wed, Thu, Fri, Sat, Sun. Mi. 21 °C 06 : 30 60 min.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 Operation and setting /adjustment SELECTING THE OPERATING MODE Use the bol or the or button to deselect the symbol. sym- Select ECO heating level or HIGH heating level using the or button. 2 2 ECO 2 2 HIGH Press the Confirm the HEATING or VENTILATION function by pressing the button. button to confirm the heating level.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 25 3 Operation and setting /adjustment ACTIVATING THE PROGRAM MEMORY 2 On Off Press the button to confirm the “On” setting. DEACTIVATING THE PROGRAM MEMORY Use the Mi. 21 °C 06 : 30 60 min. PLEASE NOTE! button to After editing the program, press the return to the PROGRAM / PRESELECTION menu item or wail until if the vehicle lighting is ON the PROGRAM / PRESELECTION menu item is displayed, if the vehicle lighting is OFF the display lighting goes out.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 Operation and setting /adjustment SETTINGS PLEASE NOTE! SETTING THE TIME Display ON, the Start display appears. or Use the in the Menu bar. Mo. button to select the Do not press the button, as otherwise SET THE TIME appears in the display again. symbol 10:30 Confirm the SETTINGS menu item by pressing the button. Confirm the SET THE TIME by pressing the ton. or Use the button to set the hours. 06 : 00 Press the button to confirm the setting.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 27 3 Operation and setting /adjustment SETTING THE WEEKDAY PLEASE NOTE! Display ON, the Start display appears. Use the or in the Menu bar. Mo. button to select the Do not press the symbol After making the setting, press the button to return to the SETTINGS menu item or wail until if the vehicle lighting is ON the SETTINGS menu item is displayed, if the vehicle lighting is OFF the display lighting goes out.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 3 Operation and setting /adjustment SETTING THE TIME FORMAT Display ON, the Start display appears. Use the or in the Menu bar. button to select the symbol 24 h Press the Mo. PLEASE NOTE! 10:30 Do not press the button, as otherwise SET THE TIME FORMAT appears in the display again. Confirm the SETTINGS menu item by pressing the button. The SET THE TIME symbol or Use the FORMAT symbol.
VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 29 4 W H AT T O D O IF …? IN THE EVENT OF A FAULT THE FOLLOWING DISPLAYS ARE POSSIBLE: DISPLAY INIT DESCRIPTION REMEDY / CUSTOMER Automatic detection is active. The EasyStart Timer has been disconnected from the power supply and then reconnected. Wait until the automatic detection has finished, then set the time and weekday. No communication. Check and if necessary renew the heater fuse. Visit your vehicle workshop. 1st heater fault.
| VEHICLE HEATERS – TECHNICAL DOCUMENTATION 5 SERVICE HOTLINE If you have any technical questions, a problem with the EasyStart Timer or the heater, dial the following service phone number from within Germany: Hotline: 0800 1234300 Fax hotline: 01805 262624 Outside of Germany, please contact the respective Eberspächer national representative.
