9.1
Metering Devices, Protective Relays, Software and Connectivity
Power Xpert Architecture
Power Xpert Architecture
Configuration Guidelines
With Power Xpert devices
(sophisticated, Web-
enabled, high-definition
communications) and a
simple Web browser,
users can interrogate single
devices directly, groups of
devices connected through
gateways, or connect
through software managing
multiple devices and
gateways. Using the Eaton
system, users are free to
combine ways in which
they view their devices.
Applications generally fall
into four primary categories.
Eaton has developed an easy
way to provide the preferred
solution, using the following
configuration deployment
strategies as example
application categories.
See Page V3-T9-8.
Configuration Guidelines
Application
Categories Level Description
Implementation
Details
Small/Smart
Hardware
installation
0 Web browser access directly to an individual Power
Xpert device, i.e., Power Xpert Meter or Eaton UPS w/
optional Power Xpert Gateway Series 2000 card
installed.
Easy configuration to enable Web browser monitoring
for a single or small amount of Eaton devices, without
coordination between devices.
Medium
installation
1 Web browser access to multiple Eaton devices and
third-party Modbus RTU devices through the Power
Xpert Gateway and/or Power Xpert Gateway Cards.
Easy setup to enable Web browser monitoring for
multiple Eaton devices, as well as third-party devices
that support Modbus RTU. Each Power Xpert Gateway/
Gateway Card acts as a standalone Web server.
Sophisticated
installation
2 Web browser access to multiple Eaton and third-party
devices through Power Xpert Software. Devices
connect to Power Xpert Software by means of either
direct Web-enabled cards installed inside or via Power
Xpert Gateways. Includes device views for Eaton
equipment as standard.
Full suite of tools available to monitor overall system
health. Power Xpert provides complete control over
centralized alarm notification, reporting and escalation.
Tailored
solution
3 Custom Web interface design using Eaton Electrical
Services group.
Integration of third-party devices and custom screens.
