Metering Devices, Protective Relays, Software and Connectivity
Metering Devices
Additional Features
Features of IQ 250 and IQ 260 Electronic Power Meters
Notes
1
Digital out with IQ 250 requires external command.
2
Requires external power supply.
Standards and Certifications
●
IEC 687: 0.2% accuracy
●
ANSI C12.20: 0.2% accuracy
●
ANSI C62.41: Burst
●
UL/cUL: Electrical and
electronic measuring and
test equipment 22CZ
Features IQ 250 IQ 260
Instrumentation
Current, per phase
■■
Current demand
■■
Calculated neutral current
■■
Voltage, per phase (L-L, L-N)
■■
Frequency
■■
Power, Energy and Demand
Real, reactive and apparent power, total and per phase (kW, kVAR, kVA)
■■
Real, reactive and apparent energy, total and per phase (kWh, kVARh, kVAh)
■■
Real, reactive and apparent power demand
■■
Power factor, total and per phase
■■
Min./max. readings, I, V, PF, F, THD (IQ 260), kW, kVAR, kVA
■■
Demand Methods
Block interval (sliding, fixed)
■■
Communications
RS-485
■■
KYZ output
■■
Modbus RTU
■■
Modbus ASCII
■■
DNP 3.0
■■
Data Logging
128 KB for data logging Opt. Opt.
I/O
Two digital in /two digital out
1
Opt. Opt.
Four digital in/four KYZ out Opt. Opt.
Four analog output (4–20 mA)
2
Opt. Opt.
Four analog output (0–1 mA) Opt. Opt.
Power Quality Analysis
Total harmonic distortion (THD) voltage and current per phase
■
Alarming
Set point driven alarm
■
