Metering Devices, Protective Relays, Software and Connectivity
Connectivity Options
Product Selection
Ordering Information
Technical Data and Specifications
The Power Xpert Gateway
Series 2000 Card Kit Includes
●
Power Xpert Gateway
Series 2000 Card
●
Ethernet cable
●
Local configuration cable
●
Quick start guide
Devices Supported
●
Powerware uninterruptible
power supplies with X-Slot
compatibility; these include
the Powerware 5115 RM,
5125, 9125, 9140, 9155,
9315, 9355, 9330, 9390,
9395, BladeUPST
Communication Ports
●
Ethernet ports: two
independent RJ-45 ports:
supports 10/100Base-T for
redundant network
configurations
●
Serial ports: one RJ-45
console port supports
local configuration and
optional connection to an
Environmental Monitoring
Probe (EMP)
Communication
Protocols Supported
●
Web server: supports
data access from Web
browsers (HTTP and
HTTPS)
●
Modbus TCP/IP: supports
data access from Modbus
TCP clients
●
SNMP: supports common
network management
tools
●
SMTP: supports e-mail
notification
●
NTP: supports time
synchronization via an
NTP server for card and
UPS synchronization
●
DHCP: supports automatic
IP address assignments,
if enabled
Supported MIBs
●
Eaton Power MIB
●
RFC 1628 UPS MIB
●
Eaton EMP MIB
●
Eaton alarms and
traps MIB
●
RFC 4133 Entity MIB
●
RFC 4268 Entity State
MIB; RFC 4268 Entity
State MIB Part 2
●
RFC 1213 MIB II
Web Browsers Supported
●
IE
●
Mozilla Firefox
Environmental
Specifications
●
Ambient operating:
0 to +40°C (32 to 104°F)
●
Relative humidity:
10 to 80%, noncondensing
●
Altitude: 10,000 ft
●
Enclosure rating: indoor
use only
Mounting Configuration
●
X-Slot form factor fits
directly into UPS chassis
Power Supply
●
Nominal input voltage:
12 Vdc, unregulated
(provided by UPS)
●
Input voltage range:
8–25 Vdc, unregulated
Power Consumption
●
2.0 watts
Dimensions
Approximate Dimensions in Inches (mm)
Physical Characteristics
Description
Style
Number
Catalog
Number
Power Xpert Gateway Series 2000 Card for use with
Powerware UPSs
103005868-5591 PXGX 2000
Power Xpert Gateway
Series 2000 Card
Height Width Depth
Weight
Lbs (kg)
1.50 (39.0) 4.70 (120.0) 4.50 (114.0) 0.44 (0.2)
