Metering Devices, Protective Relays, Software and Connectivity
Protective Relays
Options and Accessories
Test Panel (120 Vac)
Used to test the ground fault
system, to give an indication
the relay has tripped the
breaker, and to reset the relay
after tripping. These functions
may be separately mounted
pilot devices.
Note: When a mechanically reset
relay is used with a test panel,
both the relay and test panel
must be reset following either a
simulated ground fault test or
actual ground fault. Not UL listed.
Ground Fault Warning Indicator
This is an accessory item for
use with GFR relays with
interlocking circuitry. At
approximately 30–50% of
the relay pickup setting, the
indicator switches separate
120 Vac control power to a
lamp or relay (not included) to
give an indication of a ground
fault. The indicator is rated
110/120 Vac 50/60 Hz for a
maximum indicator load of
0.5 amperes.
Indicating Ammeter
The optional indicating
ammeter connects to the
sensor terminals through
a momentary contact
pushbutton, and will indicate
(in amperes) any ground fault
current flowing through the
sensor. Kit includes the
ammeter and pushbutton.
Not UL listed.
Shunt Trip Attachments
Use 120 Vac shunt trips.
Face Plate
Recommended when
these relays are semi-flush
mounted, to close the door
cutout opening.
Options
Additional optional equipment
can be added to the protection
system to meet the
requirements of the specifying
engineer, including:
●
Ground fault test panel
●
Ground fault warning
indicator relay
●
Ground fault indicating
ammeter
GFR relays are available with
zone selective interlocking
circuitry to interlock several
relays within the same system.
This allows the relay,
which detects a ground
fault, to instantly clear
the fault by tripping the
disconnect device. The relay
simultaneously sends a signal
to relay units “upstream” from
the fault to time delay or
to block their operation
completely. Current sensors
in various designs provide a
range of “window” sizes to
accommodate standard bus
and cable arrangements.
Shunt trip attachments may be
ordered for field mounting in
Eaton’s molded case circuit
breakers, or may be ordered
factory installed in the breaker.
Optional Test Panel
Ground Fault Warning Indicator
Ammeter Kit
Face Plate
Note
1
One end removable for installation.
Instruction Leaflet 15321 available as a PDF at
www.eaton.com (Go to Advanced Search and enter 15321).
Control Test
Catalog
Number
120 volt 50/60 Hz 120 volt 50/60 Hz GFRTP
Description
Catalog
Number
Manual reset 1234C67G01
Self-resetting 1234C67G02
GFR System
Used with
Kit Catalog
Number
1–12 amperes 752B820G01
5–60 amperes 752B820G02
100–1200 amperes 752B820G03
Description
Catalog
Number
Face plate 752B410G01
