Metering Devices, Protective Relays, Software and Connectivity
Protective Relays
Catalog Number Selection
The catalog number
identification chart defines
the electrical characteristics
and operation features
included in the ETR-4000.
For example, if the catalog
number were ETR-3000A0BA1,
the device would have the
following:
ETR-4000
(A)–8 Digital Inputs,
9 Output Relays
(0)–5A/1A phase and ground
CTs, Power Supply Range:
19-300 Vdc, 40–250 Vac
(B)–Modbus-RTU (RS-485)
(A)–Without Conformal
Coating
(1)–Projection Panel Mount
ETR-4000 Eaton Transformer Protection Relay
Technical Data and Specifications
Climatic Environmental
Conditions
●
Storage temperature:
–22°F to 158°F (–30°C
to +70°C)
●
Operating temperature:
–40°F to 140°F (–40°C
2
to +60°C)
●
Permissible humidity at
ann. average: <75% rel.
(on 56d up to 95% rel.)
●
Permissible installation
altitude:
●
6,561.67 ft (<2,000m)
above sea level
●
If 13,123.35 ft (4,000m)
altitude applies, a
changed classification
of the operating and test
voltages may be
necessary
Degree of Protection EN 60529
●
HMI front panel with
seal: IP54
●
Rear side terminals: IP30
Routine Test
●
Insulation test according to
IEC 60255-5: All tests to be
carried out against ground
and other input and output
circuits
●
Aux. voltage supply, digital
inputs: 2.5 kV (eff.)/50 Hz
●
Current measuring inputs,
signal relay outputs: 2.5 kV
(eff.)/50 Hz
●
Voltage measuring inputs:
3.0 kV (eff.)/50 Hz
●
All wire-bound
communication interfaces:
1. 5 k V D C
Housing
●
Material, housing:
Aluminum extruded
section
●
Material, front panel:
Aluminum/foil front
●
Mounting position:
Horizontal (±45° around
the X-axis must be
permitted)
Plug-in Connector with
Integrated Short-Circuiter
(Conventional Current Inputs)
●
Nominal current: 1A and
5A
●
Continuous loading
capacity: 4 x I
n
/
continuously
●
Overcurrent withstand:
●
30 x I
n
/10s
●
100 x I
n
/1s
●
250 x I
n
/10 ms
(1 half-wave)
●
Screws: M4, captive type
acc. to VDEW
●
Connection cross sections:
●
2 x AWG 14 (1 x or 2 x
2.5 mm
2
) with wire
end ferrule
●
2 x AWG 12 (1 x or 2 x
4.0 mm
2
) with ring cable
sleeve or cable sleeve
●
2 x AWG 10 (1 x or 2 x
6 mm
2
) with ring cable
sleeve or cable sleeve
Control Power Supply
●
Aux. voltage: 24–270 Vdc/
48–230 Vac (–20/+10%)
●
Buffer time in case of
supply failure: >= 50 ms
at minimal aux. voltage
interrupted communication
is permitted
●
Maximum permissible
making current:
●
18A peak value for
<0.25 ms
●
12A peak value for
<1 ms
●
The voltage supply must
be protected by a fuse of:
●
2.5A time-lag miniature
fuse approx. 0.2 x 0.8 in.
(5 x 20 mm) according to
IEC 60127
●
3.5A time-lag miniature
fuse approx. 0.25 x
1.25 in. (6.3 x 32 mm)
according to UL 248-14
Notes
1
Consult factory for the availability of
4 Inputs/5 Outputs, 8 Inputs/5 Outputs
and sensitive ground.
2
Display will stop working at –20°C.
Hardware Option 1
A = 8 DI, 9 outputs, removable terminals,
2 zone interlocking, URTD interface, IRIG-B,
small display
B = 4 DI, 5 outputs, removable terminals,
IRIG-B, small display
1
C = 8 DI, 5 outputs, removable terminals,
1 zone interlocking, IRIG-B, small display
1
ETR4000 A 0 B A 1
Communication Options
B = Modbus-RTU (RS-485)
1 = Modbus-RTU (RS-485) +
Modbus-TCP (RJ-45)
Conformal Coating
Options
A = None
B = Conformal coated
circuit boards
Mounting Options
0 = Standard mount
1 = Projection panel mount
Hardware Option 2
0 = Phase current 5A/1A, ground
current 5A/1A, power supply
range: 19–300 Vdc,
40–250 Vac
1 = Phase current 5A/1A sensitive
ground current, 0.5A/0.1A,
power supply range:
19–300 Vdc, 40–250 Vac
