9.3
Metering Devices, Protective Relays, Software and Connectivity
Metering Devices
Technical Data and Specifications
Enclosed Meters
Note: Specifications are subject to change without notice and represent
the maximum capabilities of the product with all options installed. This is
not a complete feature list. Features and functionality may vary depending
on selected options, firmware version and product model. Please refer to
the technical data sheet and the user manual for detailed specifications.
Description Specification
Enclosure rating NEMA 12, 3R, 4X
Enclosure operating temperature –20°C to +40°C
Note: Temperature range of meter is
–20°C to +70°C. If applied outside, proper
precautions should be taken to avoid exceeding
the maximum and minimum temperature ratings
of the meter.
Dimensions Single unit (IQ 150/250/260 and PXM 2000):
NEMA 12 (8.00W x 16.30H x 10.40D inches),
NEMA 3R/4X (8.00W x 16.30H x 9.60D inches)
Single unit (PXMP):
NEMA 12/3R/4X (24.00W x 30.00H x 12.00D inches)
Single unit (PXM 4000/6000/8000):
NEMA 12 (20.00W x 24.00H x 14.10D inches)
NEMA 3R/4X (20.20W x 24.00H x 13.90D inches)
Multi unit:
NEMA 12 (13.00W x 30.00H x 15.20D inches)
NEMA 3R (13.20W x 30.10H x 14.60D inches)
NEMA 4X (13.00W x 30.00H x 14.00D inches)
Meters Single unit: IQ 150, IQ 250/260, PXM 2000/4000/6000/8000
and PXMP models
Multi unit: IQ 35M, IQ 150 and IQ 250/260
Communications (multi unit only) Power Xpert Gateway 200E
Control voltage 120V–600V (PXMP)—power supply required
Up to 240V (IQ 35M/150/250/260 and PXM 2000/4000/
6000/8000)—no CPT required
Greater than 240V (IQ 150/250/260 and
PXM 2000)—CPT required
Separate source control—no CPT required
Basic model Fusible disconnect—primary voltage
Shorting block(s)—not required for IQ 35M or PXMP
Ground terminal block
Neutral terminal block
Eight-point terminal block(s) for input/output
modules for IQ 250/260 and PXM 2000
Wiring Wired for three-phase, four-wire applications. Three-phase,
three-wire applications—
will need to change the wiring for both the voltage and the
current per the wiring diagram in the meter instruction
manual.
Certifications UL
®
508A and cUL
®
Source control No separate source control voltage required for applications
below 240 Vac (except PXMP)
Prewired Prewired current transformer, shorting terminal block(s),
neutral, ground, voltage, control
power, fusible disconnect and input/output
terminal block(s)
Latch Padlocking latch provision
Optional features Control power transformer—single unit: 50 VA (IQ150/250/
260) and 150 VA (PXM 4000/6000/8000); multi unit: 250 VA
control power supply for meter where monitored voltage is
480 Vac (IQ150/250/260 and PXM 2000/4000/6000/8000)
