9.3
Metering Devices, Protective Relays, Software and Connectivity
Metering Devices
Approximate dimensions in inches (mm)
S080
S090
(8) Open Slots
0.47 x 0.22 (11.9 x 5.6)
5.73 (145.5)
4.85 (123.2)
3.81 (96.8)
2.19
(55.6)
H1
X1
LABEL
2.91
(73.9)
1.15
(29.2)
0.44
(11.2)
5.73
(145.5)
2.84
(72.1)
4.70
(119.4)
0.51
(13.0)
3.25 (82.6) Dia.
H1
X1
0.42 (10.7) Dia.
(4) Holes
1.09
(27.7)
0.55
(14.0)
S080BRAC
H1
X10
LABEL
5.92 (150.4)
4.85 (123.2)
3.81 (96.8)
1.15
(29.2)
2.91
(73.9)
3.50
(88.9)
6.17
(156.7)
X1
4.25 (108.0) Dia.
H1
0.42
(10.7)
4.86 (123.4)
2.97
(75.4)
(4) 0.28 x 0.63 (7.1 x 16.0) Slots
(8) Open Slots 0.47 x 0.22 (11.9 x 5.6)
2.19
(55.6)
S090BRAC
