User's Guide

ECR-2400 Node Hardware
10156-04 2 - 5 EkaNet Hardware Manual
Eka Proprietary and Confidential
Network Specifications
No hard limitation on number of meters per Gateway (actual number of meters per
Gateway depends on network performance requirements)
Full peer-to-peer communication
Fully self-configuring
Automatic routing
No network address management required
Automatic network acquisition
Automatic time synchronization of all nodes in the network
128 bit authentication/encryption
Operating Conditions
Environmental -40°C to +70°C
5 - 95% non-condensing humidity
Power Supply Internal to meter
110 - 240 VAC
Power Consumption 0.6 Watt typical
