2.3 ECR-2400 Node Specifications
Application Specifications
Compatibility ECR-2400 Meter Serial Interface
Data storage Stores 1 month of data (1 channel @ 15 min. intervals)
Data Integrity Non-volatile data storage provides extra security in the
event of communication failure or power outage
Advanced features Load profile, remote demand reset, remote connect/
disconnect capability
Radio Specifications
Operating frequency 2.400 - 2.4835 GHz
Reliable data transmission Error detection, correction and retransmission
RF output power (typical) 20 dBm
Data rate 1 Mbps
Receiver sensitivity Sensitivity -80 dBm (@ 0.1% BER, +85°C)
Range (w/ omni antenna)
Outdoor > 400 m (1200 ft.)
Indoor 25 - 50 m (75 - 150 ft.)
Mode Frequency hopping spread spectrum
Interface Specifications
Meter manufacturer proprietary protocol
Mechanical
Weight: 45 g (1.6 oz.)
Dimensions: 97 x 80 x 33 mm.
(3
7
/
8
x 3
1
/
8
x 1
1
/
3
in.)
