704.062.218 - Illuminated pushbutton actuator

Attention: The preview is based on a sample product. This can

differ from your current configuration.

Mounting

Mounting cut-out Ø 30,5 mm

Design flush

Front

Front shape round

Front dimension Ø 35 mm

Front bezel colour natural anodized

Front bezel material Aluminium

Other Attributes

Weight 0,067 kg

Operating-/Indication part

Lens optics transparent

Lens material Plastic

Lens colour red

Lens profile flat

Lens illumination illuminative

IP-Rating

Front protection IP65

Connection Method

Terminal Screw terminal

Actuator

Switching action Maintained

Housing material Plastic

Housing colour grey

Switching element

max. number of switching

elements

Illumination

LED colour red

Function

Illuminated pushbutton

Stand: 29.11.2019

PAGE 1
704.062.218 - Illuminated pushbutton actuator 704.062.218 - Illuminated pushbutton actuator Mounting Mounting cut-out Design Front Front shape Front dimension Front bezel colour Front bezel material Other Attributes Weight Attention: The preview is based on a sample product. This can differ from your current configuration.
PAGE 2
704.062.218 - Illuminated pushbutton actuator Dimensions Additional information Max. 3 switching elements can be clipped on The colour of anodized aluminium parts can vary due to technical production reasons Legend Switching action: C = Maintained X = Screw terminal Mounting cut-outs PIT = Push-in terminal Wiring diagram Stand: 29.11.2019 Powered by TCPDF (www.tcpdf.
