Installation Instruction of AM124ETL-R TS-series Control panel
Safety Information 1. Please read carefully and follow all instructions when operating. 2. Qualified earth leakage circuit-breaker must be installed and tested with trial jump to certify the device is qualified and safety before using the product. 3. To avoid electrical shock, the replacing of the wire must be done by the electrical engineer or the retailer. Customer could not replace by yourself. 4.
AM124 Water and wire line instruction diagram AM124ETL-R Component Struction No. Name No.
AM113/119/124/125/128/168/505-2 3 Installation Steps 4
A Shower head Waterfall B OFF ON Shower head Jet OFF Jet OFF ON OFF ON Two sets of the faucet: Three sets of the faucet: A.The faucet is the function conversion.Turn 90° left is the pipe cleaning function while 90° right is the shower head. A.Function conversion value.Turn 90° left is the pipe cleaning function while 90° right is the shower head. B.The cold-hot water inlet valve is both for hot and cold water.
TS Control panel instruction TS Wiring Diagram Radio antenna Speaker Only can be matched the DC12V ozone generator Water temperature probe Control panel Capacitive water level sensor 250 Crimp terminal 250 Crimp terminal 250 Crimp terminal 250 Crimp terminal Main power Thermostatic power Light (color is change automatically) Water pump power Electric parameter Spare part Parameter Massage pump Ozone generator Bottom light Thermostatic Electromagnetism valve Control panel Speaker Note Rate
TS Control panel instruction TS Control panel instruction The characteristics of the control system electrical box 1） Rated voltage: AC220V-240V/AC110V- 120V 2） Rated frequency: 50HZ/60HZ 3） Standby Power: <10W （All load is closed） 4） Ambient temperature: +5℃~+40℃ Devices being controlled by control system 1）Surfing water pump: 2HP 4）Electromagnetism valve: 4*DC12V /5W 2）Heater: 1500W 5）Ozone generator: DC12V/ 6W 3）Bottom light: DC12V/1W 6）Speaker: 8Ω/15W（Maximum） Control panel operation instructio
TS Control panel instruction 8.6.2 Channel picking out: touch “ “ ” or “ ” when the radio turns on, the LCD shows the corresponsive channel and “CH” icon, touch ” to pick out the corresponsive channel. 9. Bluetooth 9.1 When the control system turns on and the radio turns off, touch “ ” for 2 seconds to disconnect the corresponsive device and search the new device again. 9.
13 Maintenance Record 14
