Instruction Manual
PSI 8000 3U HS PV Series
Date: 10-28-2011
About the device
1. Introduction
The high efciency power supplies of the series PSI 8000 3U
are ideally suited for test systems and industrial control facilities
by their 19“ draw-out case.
Apart from standard functions of power supplies the user can
dene and recall different presets of set values, supervise set
values and actual values by denable limits or create function
runs of congurable preset values with the integrated function
manager.
Optionally available, digital interface cards provide an even
wider spectrum of control and monitoring functions by means
of a PC. Another optionally available extension card is the gal-
vanically isolated analogue interface IF-A1 which can serve to
control the device by external means, like a PLC.
The integration into existent systems is done very comfortably
by using an interface card, while there is no need to congure
the card at all or with only a few settings.
All models feature an adjustable power regulation circuit, as well
as a „Share Bus“ terminal which enables parallel connection
with symmetric current distribution.
The integrated options HS (high speed) and PV (photovoltaics)
offer a higher dynamics contrary to standard power supply mo-
dels and enable running tests which are typical for the E.U.T
stage of solar inverter production. The PV option will control the
power supply according to a certain characteristics.
The main functions at a glance:
• Set voltage, current and power, each with 0...100%
• Adjustable overvoltage threshold 0...110% U
Nom
• Optional, pluggable interface cards
(CAN, USB, RS232, IEEE/
GPIB, Ethernet/LAN, Probus)
• Optional, analogue interface for external control and monito-
ring with extended features
• Power ratings: 10kW or 15kW
• Temperature controlled fans
• Status indication (OT, OV, CC, CV) in the display
• Supervision function
• Function manager
• Adjustable internal resistance (optional)
• High speed ramping
• Parallel connection with Share bus
• Solar panel simulation with PV
2. Technical specications
2.1 Control panel and display
Type
Display Graphics display 128x64 dots
Operating controls: 6 pushbuttons, 2 rotary knobs
Displayed formats
The nominal values limit the maximum adjustable range.
Actual values and set values for voltage, current and power
are displayed simultaneously, the set value of the overvoltage
threshold is displayed seperately.
Display of voltage values
Resolution: 4 digits
Formats: 0.0…999.9V
0V...9999V
Display of current values
Resolution: 4 digits
Formats: 0.00A…99.99A
Display of power values
Resolution: 4 digits
Formats: 0.00kW…99.99kW
Display of resistance values
(only with unlocked option „internal resistance control“)
Resolution: 4 digits
Formats: 0.0Ω…999.9Ω
0Ω…9999Ω
Time displays
Times are displayes in 4 automatically switched ranges.
Resolution:
Range 1: 2ms to 9.999 s
Range 2: 10ms to 59.99s
Range 3: 1:00m to 59:59min
Range 4: 1:00h to 99:59h
Accuracy:
Range 1: 2ms
Range 2: 10ms
Range 3: 1s
Range 4: 1 min
