User manual
Table Of Contents
- 06230304_MA-PSI9000-2U-TFT-DE
- 1. Allgemeines
- 1.1 Zu diesem Dokument
- 1.2 Gewährleistung und Garantie
- 1.3 Haftungsbeschränkungen
- 1.4 Entsorgung des Gerätes
- 1.5 Produktschlüssel
- 1.6 Bestimmungsgemäße Verwendung
- 1.7 Sicherheit
- 1.8 Technische Daten
- 1.9 Aufbau und Funktion
- 1.9.1 Allgemeine Beschreibung
- 1.9.2 Blockdiagramm
- 1.9.3 Lieferumfang
- 1.9.4 Zubehör
- 1.9.5 Optionen
- 1.9.6 Die Bedieneinheit (HMI)
- 1.9.7 USB-Port (Rückseite)
- 1.9.8 Steckplatz für Schnittstellenmodule
- 1.9.9 Analogschnittstelle
- 1.9.10 Share-Bus-Anschluß
- 1.9.11 Sense-Anschluß (Fernfühlung)
- 1.9.12 Master-Slave-Bus
- 1.9.13 GPIB-Port (optional)
- 2. Installation & Inbetriebnahme
- 2.1 Transport und Lagerung
- 2.2 Auspacken und Sichtkontrolle
- 2.3 Installation
- 2.3.1 Sicherheitsmaßnahmen vor Installation und Gebrauch
- 2.3.2 Vorbereitung
- 2.3.3 Aufstellung des Gerätes
- 2.3.4 Anschließen an das Stromnetz (AC)
- 2.3.5 Anschließen von DC-Lasten
- 2.3.6 Erdung des DC-Ausgangs
- 2.3.7 Anschließen der Fernfühlung
- 2.3.8 Installation eines AnyBus-Schnittstellenmoduls
- 2.3.9 Anschließen der analogen Schnittstelle
- 2.3.10 Anschließen des „Share-Bus“
- 2.3.11 Anschließen des USB-Ports (Rückseite)
- 2.3.12 Erstinbetriebnahme
- 2.3.13 Erneute Inbetriebnahme nach Firmwareupdates bzw. längerer Nichtbenutzung
- 3. Bedienung und Verwendung
- 3.1 Personenschutz
- 3.2 Regelungsarten
- 3.3 Alarmzustände
- 3.4 Manuelle Bedienung
- 3.5 Fernsteuerung
- 3.6 Alarme und Überwachung
- 3.7 Bedieneinheit (HMI) sperren
- 3.8 Nutzerprofile laden und speichern
- 3.9 Der Funktionsgenerator
- 3.9.1 Einleitung
- 3.9.2 Allgemeines
- 3.9.3 Arbeitsweise
- 3.9.4 Manuelle Bedienung
- 3.9.5 Sinus-Funktion
- 3.9.6 Dreieck-Funktion
- 3.9.7 Rechteck-Funktion
- 3.9.8 Trapez-Funktion
- 3.9.9 DIN 40839-Funktion
- 3.9.10 Arbiträr-Funktion
- 3.9.11 Rampen-Funktion
- 3.9.12 UI- und IU-Tabellenfunktion (XY-Tabelle)
- 3.9.13 PV-Tabellenfunktion (Photovoltaik)
- 3.9.14 FC-Tabellenfunktion (Brennstoffzelle)
- 3.9.15 Fernsteuerung des Funktionsgenerators
- 3.10 Weitere Anwendungen
- 4. Instandhaltung & Wartung
- 5. Zubehör und Optionen
- 6. Service & Support
- 1. Allgemeines
- 06230304_MA-PSI9000-2U-TFT-EN
- 1. General
- 1.1 About this document
- 1.2 Warranty
- 1.3 Limitation of liability
- 1.4 Disposal of equipment
- 1.5 Product key
- 1.6 Intended usage
- 1.7 Safety
- 1.8 Technical Data
- 1.9 Construction and function
- 1.9.1 General description
- 1.9.2 Block diagram
- 1.9.3 Scope of delivery
- 1.9.4 Accessories
- 1.9.5 Options
- 1.9.6 The control panel (HMI)
- 1.9.7 USB port (rear side)
- 1.9.8 Interface module slot
- 1.9.9 Analog interface
- 1.9.10 Share Bus-Connection
- 1.9.11 Sense connector (remote sensing)
- 1.9.12 Master-Slave bus
- 1.9.13 GPIB port (optional)
- 2. Installation & commissioning
- 2.1 Transport and storage
- 2.2 Unpacking and visual check
- 2.3 Installation
- 2.3.1 Safety procedures before installation and use
- 2.3.2 Preparation
- 2.3.3 Installing the device
- 2.3.4 Connection to AC supply
- 2.3.5 Connection to DC loads
- 2.3.6 Grounding of the DC output
- 2.3.7 Connection of remote sensing
- 2.3.8 Installation of an AnyBus interface module
- 2.3.9 Connecting the analog interface
- 2.3.10 Connecting the “Share” bus
- 2.3.11 Connecting the USB port (rear side)
- 2.3.12 Initial commission
- 2.3.13 Commission after a firmware update or a long period of non-use
- 3. Operation and application
- 3.1 Personal safety
- 3.2 Operating modes
- 3.3 Alarm conditions
- 3.4 Manual operation
- 3.5 Remote control
- 3.6 Alarms and monitoring
- 3.7 Control panel (HMI) lock
- 3.8 Loading and saving a user profile
- 3.9 The function generator
- 3.9.1 Introduction
- 3.9.2 General
- 3.9.3 Method of operation
- 3.9.4 Manual operation
- 3.9.5 Sine wave function
- 3.9.6 Triangular function
- 3.9.7 Rectangular function
- 3.9.8 Trapezoidal function
- 3.9.9 DIN 40839 function
- 3.9.10 Arbitrary function
- 3.9.11 Ramp Function
- 3.9.12 UI and IU table functions (XY table)
- 3.9.13 PV table function (photovoltaics)
- 3.9.14 FC table function (fuel cell)
- 3.9.15 Remote control of the function generator
- 3.10 Other applications
- 4. Service and maintenance
- 5. Accessories and options
- 6. Service & Support
- 1. General

Seite 20
PSI 9000 2U Serie
www.elektroautomatik.de
ea1974@elektroautomatik.de
EA Elektro-Automatik GmbH
Helmholtzstr. 31-33 • 41747 Viersen
Telefon: 02162 / 3785-0
Telefax: 02162 / 16230
(1BezogenaufdenNennwertdeniertdieGenauigkeitdiemaximaleAbweichungzwischenSollwertundIstwert.
Beispiel: ein 80 V-Gerät hat min. 0,1% Spannungsgenauigkeit, das sind 80 mV. Bei einem Sollwert von 5 V dürfte der Istwert also max. 80 mV abweichen, sprich
er dürfte 4,92 V...5,08 V betragen.
(2 RMS-Wert: NF 0...300 kHz, PP-Wert: HF 0...20MHz
(3 Typischer Wert bei 100% Ausgangsspannung und 100% Last
(4 Der Fehler der Anzeige addiert sich zum Fehler des Istwertes am DC-Ausgang
3000 W
Modell 2U
PSI 9360-30 PSI 9500-20 PSI 9750-12
AC-Eingang
Netzspannung 180...264 V AC 180...264 V AC 180...264 V AC
- mit zusätzlichem Derating 180...207 V AC 180...207 V AC 180...207 V AC
Netzanschluß 1ph,N,PE 1ph,N,PE 1ph,N,PE
Netzfrequenz 50/60 Hz 50/60 Hz 50/60 Hz
Netzsicherung (intern) T16 A T16 A T16 A
Ableitstrom < 3,5 mA < 3,5 mA < 3,5 mA
Leistungsfaktor > 0,99 > 0,99 > 0,99
DC-Ausgang
Maximale Spannung U
Nenn
360 V 500 V 750 V
Maximaler Strom I
Nenn
30 A 20 A 12 A
Maximale Leistung P
Nenn
3000 W 3000 W 3000 W
Maximale Leistung P
Nenn
bei Derating 2500 W 2500 W 2500 W
Überspannungsschutzbereich 0...396 V 0...550 V 0...825 V
Überstromschutzbereich 0...33 A 0...22 A 0...13,2 A
Überleistungsschutzbereich 0…3300 W 0…3300 W 0…3300 W
TemperaturkoefzientderEinstell-
werteΔ/K
Strom / Spannung: 100 ppm
Spannungsregelung
Einstellbereich 0...360 V 0...500 V 0...750 V
Genauigkeit
(1
(bei 23 ± 5°C) < 0,1% U
Nenn
< 0,1% U
Nenn
< 0,1% U
Nenn
Stabilitätbei±10%ΔU
AC
< 0,02% U
Nenn
< 0,02% U
Nenn
< 0,02% U
Nenn
Stabilität bei 0...100% Last < 0,05% U
Nenn
< 0,05% U
Nenn
< 0,05% U
Nenn
Anstiegszeit10...90%ΔU Max. 30 ms Max. 30 ms Max. 30 ms
Anzeige:Einstellauösung Siehe Abschnitt „1.9.6.4. Auösung der Anzeigewerte“
Anzeige: Genauigkeit
(4
≤0,2%U
Nenn
≤0,2%U
Nenn
≤0,2%U
Nenn
Restwelligkeit
(2
< 210 mV
PP
< 59 mV
RMS
< 190 mV
PP
< 48 mV
RMS
< 212 mV
PP
< 60 mV
RMS
Kompensation Fernfühlung Max. 5% U
Nenn
Max. 5% U
Nenn
Max. 5% U
Nenn
Entladezeit (Leerlauf) nach
Ausschalten des DC-Ausgangs
Von 100% Spannung auf <60 V: weniger als 10 s
Stromregelung
Einstellbereich 0...30 A 0...20 A 0...12 A
Genauigkeit
(1
(bei 23 ± 5°C) < 0,2% I
Nenn
< 0,2% I
Nenn
< 0,2% I
Nenn
Stabilitätbei±10%ΔU
AC
< 0,05% I
Nenn
< 0,05% I
Nenn
< 0,05% I
Nenn
Stabilitätbei0...100%ΔU
OUT
< 0,15% I
Nenn
< 0,15% I
Nenn
< 0,15% I
Nenn
Restwelligkeit
(2
< 17 mA
PP
< 6 mA
PP
< 3 mA
PP
Anzeige:Einstellauösung Siehe Abschnitt „1.9.6.4. Auösung der Anzeigewerte“
Anzeige: Genauigkeit
(4
≤0,2%I
Nenn
≤0,2%I
Nenn
≤0,2%I
Nenn
Ausregelzeit 10%->90% Last < 1,5 ms < 1,5 ms < 1,5 ms
Leistungsregelung
Einstellbereich 0…3000 W 0…3000 W 0…3000 W
Genauigkeit
(1
(bei 23 ± 5°C) < 1% P
Nenn
< 1% P
Nenn
< 1% P
Nenn
Stabilitätbei±10%ΔU
AC
< 0,05% P
Nenn
< 0,05% P
Nenn
< 0,05% P
Nenn
Stabilitätbei10-90%ΔU
DC
*ΔI
DC
< 0,75% P
Nenn
< 0,75% P
Nenn
< 0,75% P
Nenn
Anzeige:Einstellauösung Siehe Abschnitt „1.9.6.4. Auösung der Anzeigewerte“
Anzeige: Genauigkeit
(4
≤0,85%P
Nenn
≤0,85%P
Nenn
≤0,8%P
Nenn
Wirkungsgrad
(3
~ 93% ~ 93% ~ 93%
