PSI 9000 2U Series
1.9.3 Scope of delivery
1 x Power supply device PSI 9000 2U
1 x Mains cord, 2 m, Euro plug (Schuko) and/or UK plug (depending on shipping destination)
1 x Printed operating guide
1 x Share Bus plug (separately or plugged)
1 x Remote sensing plug (separately or plugged)
1 x USB cable, 1.8 m
1 x Set of mounting brackets (for converting between 19” <-> desktop)
1 x CD “Drivers & Tools“
1.9.4 Accessories
For these devices the following accessories are available:
Digital interface modules
IF-AB
Pluggable and retrottable AnyBus interface modules for RS232, CANopen,
Ethernet, Probus, ProNet, ModBus or Devicenet are available. Others upon
request. Details about the interface modules and the programming of the device
using those interfaces can be found in separate documentation. It is usually
available on the CD, which is included with the device, or as PDF download on
the manufacturers website.
1.9.5 Options
These options are usually ordered along with the device, as they are permanently built in or precongured during
the manufacturing process. Retrotting upon request.
CABINET
19“-rack
Racks in various congurations up to 42U as parallel systems are available, or
mixed with electronic load devices to create test systems. Further information in
our catalogue or upon request
HS
„High-Speed Ramping“
Increased output voltage dynamics through reduced output capacity.
NOTE: other output values, as well as ripple also increase. This is a permanent
feature which cannot be switched off.
3W
GPIB interface
Replaces the standard slot for pluggable interface modules by a rigidly installed
GPIB port. This option can be retrotted upon request. The device will keep the
USB and analog interfaces. Via the GPIB port, it can only support SCPI commands.
