Owner’s Guide 622009 ISSUED JULY 2011 REVISED APRIL 2014
WELCOME Thank you for purchasing this vehicle. Before driving the vehicle, we ask you to spend some time reading this Owner’s Guide. This guide contains the information that will assist you in maintaining this highly reliable vehicle. Some illustrations may show items that are optional for your vehicle. This guide covers the operation of several vehicles; therefore, some illustrations may not represent your vehicle. Physical differences in controls will be illustrated.
FOREWORD Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. OWNER’S GUIDE GASOLINE POWERED VEHICLE EXPRESS S6 EXPRESS L6 STARTING MODEL YEAR 2012 Never modify the vehicle in any way that will alter the weight distribution of the vehicle, decrease its stability or increase the speed beyond the factory specifications. Such modifications can cause serious personal injury or death.
FOREWORD Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. This vehicle has been designed and manufactured in the United States of America (USA) as a ‘World Vehicle’. The Standards and Specifications listed in the following text originate in the USA unless otherwise indicated. The use of non Original Equipment Manufacturer (OEM) approved parts may void the warranty. Overfilling battery may void the warranty.
TABLE OF CONTENTS Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. SECTION PAGE NO. SAFETY............................................................................................................................................................................... 1-1 GENERAL SPECIFICATIONS.....................................................................................................................
TABLE OF CONTENTS Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. TITLE PAGE NO. SAFETY................................................................................................................................................................. 1-3 NOTICES, CAUTIONS, WARNINGS, AND DANGERS......................................................................................... 1-3 GENERAL .........................
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. SAFETY 1 For any questions on material contained in this manual, contact an authorized representative for clarification. Read and understand all labels located on the vehicle. Always replace any damaged or missing labels. On steep hills it is possible for vehicles to coast at greater than normal speeds encountered on a flat surface.
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 1 Engine exhaust from this product contains chemicals known, in certain quantities, to cause cancer, birth defects, or other reproductive harm. NOTICE The exhaust emissions of this vehicles’ engine complies with regulations set forth by the Environmental Protection Agency (EPA) of the United States of America (USA) at time of manufacture.
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. GENERAL All vehicles can be used for a variety of tasks beyond the original intended use of the vehicle; therefore, it is impossible to anticipate and warn against every possible combination of circumstances that may occur. No warning can take replace good common sense and prudent driving practices.
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 1 • apply service brake to control speed on steep grades • maintain adequate distance between vehicles.
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. LABELS AND PICTOGRAMS 1 1. To Prevent Roll-Back 2. Apply Service Brake With On a Hill From a Left Foot Stopped Position ! 4. Depress Accelerator While 3. Fully Releasing Service Brake As Release Vehicle Starts Park Brake 74443G01 74443G01 WARNING H OR N Windshields do not provide protection from golf balls or other flying objects.
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 1 ! WARNING 1. 9. 2. READ MANUAL < 14û25% SECURE LOAD MAX AS FAR FORWARD XXX lbs. AS POSSIBLE. XXX kg MAXIMUM LOAD BED CAPACITY 10. WARNING USE CAUTION IN INCLEMENT WEATHER 3. ! 4. 5. MAXIMUM CROSS HILL/RAMP ANGLE AS SPECIFIED MAX 14û/ 25% ! 6. 8. 12. PP WARNING MAXIMUM CROSS HILL/RAMP ANGLE AS SPECIFIED < 14û 25% 7.
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 1 3 1 15. 16. 17. 18. H2O PP PP CLEAN UP GASOLINE SPILLS WITH WATER BEFORE STARTING ENGINE UNLEADED GASOLINE DO NOT SPILL FUEL ON A HOT ENGINE PP PP GROUND FUEL PUMP 19. LOW OIL PRESSURE 20. NEGATIVE GROUND BATTERY 21. DO NOT CONNECT POSITIVE BATTERY TERMINAL TO GROUND 22. SHORTING BATTERY TERMINALS MAY CAUSE EXPLOSION NO 23.
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 1 OPERATE FROM DRIVERS SIDE ONLY 36. KEEP ARMS AND LEGS WITHIN VEHICLE 37. KEEP CLEAR HAND OR FINGERS CAN BE TRAPPED 42. 43. ON ON POSITION 44. OFF OFF POSITION 45. 38. F 39. 40.
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 1 51. ENGINE CRANKING POSITION START P PULL HANDLE UP TO ENGAGE PARK BRAKE 52. 1 53. 2 3 PULL HANDLE UP, PUSH BUTTON IN, PUSH HANDLE DOWN TO RELEASE PARK BRAKE WARNING READ OWNER'S MANUAL BEFORE OPERATING VEHICLE IN FORWARD OR REVERSE 54. 55. REAR DIFFERENTIAL LOCK SWITCH 59.
SAFETY Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
GENERAL SPECIFICATIONS Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. TITLE PAGE NO. EXPRESS S6 Vehicle Specifications .............................................................................................................................. 2 - 3 EXPRESS L6 Vehicle Specifications ..........................................................................................................................
GENERAL SPECIFICATIONS Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
GENERAL SPECIFICATIONS Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 2 MODEL: EXPRESS S6 TYPE: GAS POWERED PERSONNEL CARRIER (CARB) MODEL YEAR: 2012 Part No: 618868 PRODUCT SPECIFICATION CONFIGURATION HIGHLIGHTS Engine: 13 hp (9.7 kW) Exceeds SAE J1940 Standard, 4 cycle, 24.
GENERAL SPECIFICATIONS Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 2 MODEL: EXPRESS L6 TYPE: GAS POWERED PERSONNEL CARRIER MODEL YEAR: 2012 Part No: 618866 PRODUCT SPECIFICATION CONFIGURATION HIGHLIGHTS Engine: 13 hp (9.7 kW) Exceeds SAE J1940 Standard, 4 cycle, 24.
GENERAL SPECIFICATIONS Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 2 73.0 in. (185.0 cm) 93.5 in. (237.0 cm) Front 37.5 in. (95.0 cm) 5.0 in. (13.0 cm) 141.8 in. (360.0 cm) Rear 38.5 in. (98.0 cm) 49.0 in. (124.0 cm) EXPRESS S6 76.0 in. (193.0 cm) 52.5in. (133.5 cm) 99.0 in. (241.0 cm) Front 37.5 in. (95.0 cm) 138.0 in. (351.0 cm) Rear 38.5 in. (98.0 cm) EXPRESS L6 46.5 in. (119.
GENERAL SPECIFICATIONS Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. EXPRESS S6 2 REC OMMENDED MAX RAMPGRADE 25% or 14° MAX REC OMMENDED M AX SIDETILT 25% or 14° MAX TURNING CLEARANCE DIAMETER 2- 6 EXPRESS S6 35 ft 6inches (10.8 m) EXPRESS L6 25 ft 6inches (7.
GENERAL SPECIFICATIONS Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
GENERAL SPECIFICATIONS Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
INTRODUCTION Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. TITLE PAGE NO. FEATURES.......................................................................................................................................................................... 3-3 General Information ..................................................................................................................................
INTRODUCTION Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
INTRODUCTION Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. FEATURES General Information NOTICE If the vehicle is equipped with factory installed custom accessories, some accessories remain operational with the key switch in the ‘OFF’ position. 3 1 OFF ON E 13 F FUEL 2 13 10 6 7 H ORN K PAR 5 9 4 Reverse Forward 12 1.
INTRODUCTION Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 3. FUEL GAUGE The fuel gauge (if equipped) will either be located on the dash panel (electric) or directly on the fuel tank (mechanical). 4. Direction Selector 3 To reduce the possibility of component damage, the vehicle must be completely stopped before moving the direction selector.
INTRODUCTION Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 11. Front Lights If the vehicle is equipped with lights, the key switch has a position to operate them, indicated by the light icon. 12. Brake Light/Turn Signal The combination brake light/turn signal assemblies are located on the rear fenders. 3 13. Grab Handles The vehicle is equipped with grab handles. 14 16 H ORN 19 15 18 17 14.
INTRODUCTION Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 16. Steering Wheel The steering wheel located in front of the driver seat is used to steer the vehicle. The steering wheel is also installed with scorecard holder assembly. 17. Choke 3 The choke is used to aid cold starting . See COLD STARTING section for operating instructions. 18.
INTRODUCTION Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
INTRODUCTION Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
OPERATING PROCEDURES Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. TITLE PAGE NO. SERIAL NUMBER LOCATION ............................................................................................................................................ 4-3 BEFORE INITIAL USE ..........................................................................................................................................
OPERATING PROCEDURES Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
OPERATING PROCEDURES Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. SERIAL NUMBER LOCATION Two serial number and manufacture date code plates are on the vehicle. One is placed on the body below the front, driver side of the seat. The other is located on the chassis between the seat back supports. To access it, raise the seat and lift up the flap on the access panel.
OPERATING PROCEDURES Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. BEFORE INITIAL USE Read and follow the safety label on the instrument panel. Be sure you understand how to operate the vehicle and its equipment as well as how to use it safely. Maintaining good performance depends to a large extent on the operator.
OPERATING PROCEDURES Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. To reduce the possibility of severe injury or death resulting from improper vehicle operation, the following warnings must be observed: Refer to GENERAL SPECIFICATIONS for seating capacity. Depressing accelerator pedal will release foot operated park brake and may cause inadvertent vehicle movement.
OPERATING PROCEDURES Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. Oil dipsticks are unique to this model vehicle. Do not interchange oil dipsticks between models. The oil should be changed in accordance with the Periodic Service Schedule while the engine is warm. See SERVICE AND MAINTENANCE for checking oil level and changing oil procedures.
OPERATING PROCEDURES Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. Do not hold vehicle on hill by using accelerator and engine. This will cause premature and excessive wear to drive train components. To reduce the possibility of permanent damage to the drive system, it is important to prevent excessive roll-back when starting the vehicle on a hill.
OPERATING PROCEDURES Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. Fuel 1" Min. (2.5 cm) 4 Fueling BATTERY Excessive use of accessories may drain the battery and leave insufficient reserve to start the vehicle. The vehicle uses a combination starter/generator to both start the engine and charge the battery. The engine will not idle; therefore, the battery cannot be charged while the vehicle is stopped.
OPERATING PROCEDURES Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
OPERATING PROCEDURES Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. TITLE PAGE NO. VEHICLE CLEANING AND CARE ......................................................................................................................................5-5 Vehicle Cleaning .........................................................................................................................................................
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. TITLE PAGE NO. LUBRICATION...................................................................................................................................................................5-22 SPARK PLUGS ...............................................................................................................................................
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. VEHICLE CLEANING AND CARE Vehicle Cleaning To reduce the possibility of severe injury or vehicle damage, read and understand all instructions supplied by manufacturer of pressure washer. When pressure washing exterior of vehicle, do not use pressure in excess of 700 psi.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. COMMON SENSE OPERATION To prevent severe injury or death, observe the following: Never transport loaded firearms on or in vehicle Check that firearms are unloaded with the safety engaged and are properly secured with muzzle pointing in a safe direction before operating vehicle. Be aware of other firearms in proximity to operator and passengers.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. REPAIR Some servicing operations may require the front wheels, the rear wheels, or the entire vehicle to be raised. To reduce the possibility of severe injury or death from a vehicle falling from a jack: Be sure the vehicle is on a firm and level surface. Never get under a vehicle while it is supported by a jack.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. 5 WHEELS AND TIRES A tire explosion can cause severe injury or death. Never exceed the inflation pressure rating on the tire sidewall. To reduce the possibility of tire explosion, pressurize tire with small amounts of air applied intermittently to seat beads. Due to the low volume of the small tires, overinflation can occur in seconds.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. Tire plug tools and plugs are available at most automotive parts outlets and have the advantage of not requiring the tire be removed from the wheel. If the tire is flat, remove the wheel and inflate the tire to the maximum recommended pressure for the tire. Immerse the tire in water to locate the leak and mark with chalk.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. LIGHT BULB REPLACEMENT Inside of Cowl Headlight Casing To reduce the possibility of premature bulb failure, do not touch new bulbs with bare fingers. Use clean, dry tissue or paper towel to handle the glass portion of the bulb.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. TRANSPORTING VEHICLE TOWING This vehicle is not designed to be towed It is recommended that the vehicle be moved by placing the entire vehicle on a trailer, flatbed truck or other suitable transport.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. GENERAL SPECIFICATIONS for vehicle weight) and load plus 1000 lbs. (454 kg). Secure the vehicle using ratchet tie downs. SERVICE AND MAINTENANCE To reduce the possibility of severe injury or death from improper servicing techniques: 5 DO NOT attempt any type of servicing operations before reading all notes, cautions and warnings in this manual.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. ROUTINE MAINTENANCE To prolong vehicle life, some maintenance items must be serviced more frequently on vehicles used under severe driving conditions such as extreme temperatures, extreme dust/debris conditions, or frequent use with maximum load.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. Remove the dipstick and wipe off the entire area with a lint free cloth. 5 Insert the dipstick fully into the dipstick hole and remove. Examine the level of the oil on the dipstick.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. The selection of oil is dependent upon the service that the vehicle will perform. Most vehicles require 10W-30 oil, whereas vehicles used at capacity or near capacity load applications will utilize 10W-40 oil after a break-in period of 100 hours.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. Inspect the filter. Make sure the ‘O’ ring is not left on the engine surface. 5 Be careful of hot oil when drained. It may be hot enough to burn you severely Drain the oil by removing the drain plug found at the rear of the engine base. Remove using a 3/4" wrench. At the first oil change, small metal chips and lint may be found.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. As a final check, check the oil level again with the vehicle on level ground. Like all liquids, oil increases in volume when warm. The full ‘H’ mark on the dipstick is calibrated for an engine at operating temperature. When the engine is cold, the oil will be below the full mark.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. Adjusting The Belt Loosen the starter/generator pivot bolt. While holding the lower adjusting nut with a wrench, loosen the upper jam nut with another wrench. Move the lower nut up or down the adjustment bolt until proper belt tension is achieved. Hold the lower nut in place and tighten the upper jam nut against it.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. BRAKES To reduce the possibility of severe injury or death, always evaluate pedal travel before operating a vehicle to verify some braking function is present. All driving brake tests must be done in a safe location with regard for the safety of all personnel.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. ping distance from the point at which the brakes were latched. The vehicle should stop within the ‘normal’ range of stopping distances. If the vehicle stops more than 4 ft. (1.2 m) beyond the acceptable stopping distance or pulls to one side, the vehicle has failed the test and should be tested again.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. Fill / Check Plug 5 Drain Plug AIR CLEANER INSPECTION AND REPLACEMENT The air cleaner unit on the vehicle is a dry unit. Do not use oil on the filter element or any part of the unit. To aide installation and sealing, petroleum jelly may be applied to back side of cover tabs and each side of filter seal.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. LUBRICATION Do not use more than three (3) pumps of grease in any grease fitting at any one time. Excess grease may cause grease seals to fail or grease migration into areas that could damage components. Putting more than three pumps of grease in a grease fitting could damage grease seals and cause premature bearing failure.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. PROLONGED STORAGE To reduce the possibility of severe injury or death resulting from a possible explosion: Do not handle fuel in an area that is not adequately ventilated. Do not smoke near the fuel tank or refuel near open flame or electrical items which could produce a spark. Store vehicle in a clean, dry area.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. PERIODIC SERVICE SCHEDULE Check Clean, Adjust, etc. Replace To perform service that is listed in this schedule but not described in this manual, contact a local Service Representative or see the Repair and Service Manual for this vehicle.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. CAPACITIES AND REPLACEMENT PARTS Fuel Tank / Fuel 5.3 gal (20.0 liters) / 87 Octane Min Engine Oil 1.4 US qt (1.3 liters) Oil Filter P/N 607454 Air Filter P/N 28463G01 Spark Plug NGK BPR2ES (P/N 607462) .028” - .031" (.7 mm - .8 mm) Gap 5 Starter/Generator Belt P/N 26414G1 Clutch Belt P/N 618630 Rear Axle Oil 51 oz (1.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
MAINTENANCE Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
APPENDIX A Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers. TABLE OF CONTENTS FOR APPENDIX A TITLE PAGE NO. DECLARATION OF CONFORMITY .................................................................................................................................................................
APPENDIX A Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
APPENDIX A Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
APPENDIX A Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
APPENDIX A Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
APPENDIX A Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
E-Z-GO Division of Textron Inc., 1451 Marvin Griffin Road, Augusta, Georgia 30906 - 3852 USA Service Parts Manuals, as well as Repair and Service Manuals are available from a local Distributor, an authorized Branch, Genuine E-Z-GO Parts & Accessories Department or at www.shopezgo.com. Copyrighted Material This manual may not be reproduced in whole or in part without the express permission of E-Z-GO Division of Textron Inc.
