User Manual

Appendix: Technical Specifications
30
Communication ports
COM1 Built-in Infra Red communication port DISPLAY unit
RS232 communication, TTL level, max baud rate 19.2 kb/s
Protocols MODBUS RTU/ASCII and DNP3.0
Optically isolated 2500V AC @ 1mn
IR port
Basic
Optical port per ANSI C12.18 Type 2
COM2 Plug-in modules isolated communication port
RS232 communication, TTL level, max baud rate 115.2 kb/s
Isolation 2500V AC @ 1mn
GSM/GPRS module Quad Band GPRS class10
Antenna connection Coax cable terminated with SMA
connector
Protocols MODBUS/TCP or DNP3.0/TCP
MODEM module Telephone Line according to FCCp.68
and TBR21
Line connection RJ11
GSM/GPRS
MODEM
Optional module
1
Protocols MODBUS/RTU, MODBUS/TCP or
DNP3.0, DNP3.0/TCP
COM3 Built-in serial communication port
RS-485 isolated 115.2 kb/s
Isolation 2500V AC @ 1mn
Protocols MASTER/SLAVE MODBUS RTU/ASCII
and DNP3.0
basic
Terminals for wires size 2 x 2.5 mm
2
shielded twisted cable
Plug-in modules isolated communication port
Versatile RS-232/RS-485
Max. Baud rate 115.2 kb/s
Isolation 2500V AC @ 1mn
Protocols MODBUS RTU/ASCII and DNP3.0
COM4
ETH-TX
MODEM
Optional module
1
Terminals for wires size 5 x 2.5 mm
2
shielded twisted cable
Plug-in modules network communication port
Wired LAN communication port with auto-
negotiation
IEEE 802.3
Ethernet port Baud rate 10/100 Mb/s
Protocols MODBUS/TCP or DNP3.0/TCP
protocols and IEC 61850-8-1, up to
five non-intrusive simultaneous
connections, Telnet service port
ETH port Isolation 2500V AC @ 1mn
10/100Base-T
ETH-TX
Optional module
1
ETH connector ETH cable terminated with Standard
RJ-45 connector
Communication port Basic
USB communication port Full speed Device
USB port Baud rate 12 Mb/s
USB – FS device
basic
Protocols MODBUS RTU/ASCII and DNP3.0
1
Factory/Meter shop installable
