Instruction manual

EFLH2228Y VerticalFin,Yelloww/oDecals:BMCX
EFLH2229 Decal Sheet, Red Graphics: BMCX
Optional Parts List
EFLH2216GL Swashplate Set, Glow in the Dark: BMCX
EFLH2220GL Lower Main Blade Set, Glow in the Dark (1 pr): BMCX
EFLH2221GL Upper Main Blade Set,Glow in the Dark (1 pr): BMCX
EFLH2222GL Landing Skid & Batt Mnt Set, Glow in the Dark:BMCX
EFLH2224GL Main Frame Set, Glow in the Dark: BMCX
EFLH2227W Body/Canopy, White w/o Decals: BMCX
EFLH2228GL Vertical Fin, Glow in the Dark w/o Decals: BMCX
EFLH2228W Vertical Fin, White w/o Decals: BMCX
EFLH2230 Decal Sheet, Blue/Silver Graphics: BMCX
Warranty Period
Horizon Hobby, Inc., (Horizon) warranties that the Products purchased (the
“Product”) will be free from defects in materials and workmanship at the
date of purchase by the Purchaser.
Limited Warranty
(a) This warranty is limited to the original Purchaser (“Purchaser”) and
is not transferable. REPAIR OR REPLACEMENT AS PROVIDED UNDER
THISWARRANTYISTHEEXCLUSIVEREMEDYOFTHEPURCHASER.This
warranty covers only those Products purchased from an authorized Horizon
dealer. Third party transactions are not covered by this warranty. Proof of
purchase is required for warranty claims. Further, Horizon reserves the right
to change or modify this warranty without notice and disclaims all other
warranties, express or implied.
(b)Limitations-HORIZONMAKESNOWARRANTYORREPRESENTATION,
Replacement Parts List
EFLB1101S 110mAh 1S 3.7V LiPo: BMCX
EFLC1003 1S 3.7V Li-Po Charger, 0.3A: BMCX
EFLH1064 MLP4DSM 4-Channel Transmitter, 2.4GHz: BMCX
EFLH1065 5-in-1 Control Unit,RX/Servos/ESCs/Mixer/Gyro:BMCX
EFLH1066 Replacement Servo Unit: BMCX
EFLH2209 Motor w/Pinion, Left: BMCX
EFLH2210 Motor w/Pinion, Right: BMCX
EFLH2211 Inner Shaft Main Gear: BMCX
EFLH2212 Inner Shaft w/Head/Hub: BMCX
EFLH2213 Outer Shaft, Main Gear and Bushing Holder Set: BMCX
EFLH2214 Outer Shaft Retaining Collar Set: BMCX
EFLH2215 Outer Shaft Bearing, 3x6x2mm (2): BMCX
EFLH2216 Swashplate Set: BMCX
EFLH2217 Lower Rotor Head & Linkage Set: BMCX
EFLH2218 Servo Pushrod Set: BMCX
EFLH2219 Stabilizer Flybar Set: BMCX
EFLH2220 Lower Main Blade Set (1 pair): BMCX
EFLH2221 Upper Main Blade Set (1 pair): BMCX
EFLH2222 Landing Skid and Battery Mount Set: BMCX
EFLH2223 Tail Boom: BMCX
EFLH2224 Main Frame Set: BMCX
EFLH2225 Hardware Set: BMCX
EFLH2226 Body/Canopy Mounting O-Ring (8): BMCX
EFLH2227Y Body/Canopy,Yelloww/oDecals:BMCX
