Controls and Display
Callback Notifies a user waiting in a busy state
that their call has started.
1500Hz for 50ms, 0Hz for 50ms,
1000Hz for 50ms, 0Hz for 50ms,
1500Hz for 50ms
Channel Busy Indicates that the channel the user was
attempting to transmit on is busy.
300Hz for 150ms, 0Hz for 150ms,
300Hz for 150ms, 0Hz for 150ms,
300Hz for 150ms, 0Hz for 150ms,
300Hz for 150ms, 0Hz for 150ms
(played every 1200ms)
Clear Alert Warns the user that they are
transmitting or receiving a clear call.
700Hz for 50ms
Click Indicates that the soft buttons menu
has been moved left or right.
1500Hz for 3ms, 200Hz for 5ms
Double Click Indicates that the soft buttons menu
has been moved to its start or end.
1500Hz for 3ms, 200Hz for 5ms,
0Hz for 75ms, 1500Hz for 3ms,
200Hz for 5ms
DTMF Played during buttons presses for
DTMF features (Over dial and Keypad
DTMF).
1000HZ for 100ms
Dynamic Regroup Notifies the user that their radio has
been dynamically regrouped.
765Hz for 25ms, 0Hz for 25ms
(played 6 times)
Emergency Played when the user enters
emergency (and doesn’t have the radio
programmed for silent emergency).
1000Hz for 175ms
Emergency Cancel Played when the user cancels
emergency mode (and doesn’t have
the radio programmed for silent
emergency).
1000Hz for 1000ms
Emergency Status Echo Notifies the user that their emergency
alarm was received by the system.
Also notifies the user that they have
received an emergency call.
1000Hz for 175ms, 0Hz for 50ms,
1000Hz for 175ms, 0Hz for
150ms, 1000 for 175ms, 0Hz for
150ms, 1000 for 175ms, 0Hz for
150ms, 1000 for 175ms
Enter Mode A mode (e.g. Call Alert) has been
entered.
1000Hz for 50ms, 0Hz for 50ms,
1500Hz for 50ms
Error Indicates that the radio is currently in
an error condition.
300Hz for 100ms (played forever)
Evac Alert Notifies the user that an evacuation
command has been received.
932Hz for 150ms, 784Hz for
150ms (played forever)
Exit Mode A mode (e.g. Call Alert) has been
exited.
1500Hz for 50ms, 0Hz for 50ms,
1000Hz for 50ms
Failsoft Notification that the radio is in Failsoft. 1000Hz for 50ms, 0Hz for 50ms
(played 2 times)
Feature Off A feature (e.g. secure mode) has been
turned off.
1000Hz for 50ms, 0Hz for 50ms,
500Hz for 50ms
Good OTAR : Hello ack received
Roaming Diagnostic Mode: Found
control channel.
1500Hz for 50ms
Key Fail Signals an encryption key failure. 1000Hz for 125ms, 0Hz for 75ms
(played 6 times)
Table 2.5 Tones for the Viking Portable Radios
Message Name Usage Description Audible Description
