EF-IL Usermanual
The Wi-Fi CERTIFIED Logo The Spotify Software is subject to third party © Apple, the Apple logo, Airplay, iPad, licenses found here: iPhone, and iPod touch are trademarks of www.spotify.com/connect Apple Inc., registered in the U.S. and other /third-party-licenses. countries. App Store is a service mark of is a certification mark of the Wi-Fi Alliance. Apple Inc. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
CONTROLS
REAR VIEW MIC AC Power
! KEY REQUIREMENTS NETWORK: Your network must have a high-speed internet connection, as the EF-IL system is designed to utilize free, online software updates. PLEASE NOTE: ROUTER: High-speed DSL/cable modem, or fiber-to-the-home broadband connection for proper playback of internet-based music services. Different routers provide different levels of performance. Please use a good wireless router to achieve the best possible performance.
CONNECTING TO THE NETWORK YOUNEEDTHIS Wireless router with internet connection. iOS or Android device connected to your network.
1. CONNECT TO POWER Press the source button, the green indicator will start to flash. The speaker is ready for setup. 100-240v 50-60Hz 30-60s Place the speaker close to the router when carrying out the setup. You can subsequently view the signal strength in the app in order to test other positions.
2. DOWNLOAD THE APP Searchfor“E+FControl” Launch the app and followthe instructions. 3. ADD A SPEAKER ❶ Go to Wi-Fi setting of your mobile device and select your “E+F” device as network. ❷ Go back to E+F app ❸ Select your Wi-Fi network with internet connection and input password as promoted. ❹ When the device is added successfully, Go back to Wi-Fi setting of your mobile device and select your Wi-Fi network with internet connection. ❺ Go to the E+F app to find the speaker.
APP OVERVIEW MAIN VIEWS 1. Music services and sources 2. Player view 3.
4. MultiRoom 5. Setting 6.
GROUPING SPEAKERS Select MultiRoom in themenu bar Tab“ + ” at the right of the speaker in the upper column to add it with the master speaker in the below column as a group. Music will play on all speakers in a group. Their volumes can be adjusted separately.
MAKING A PRESET 1. ON THE SPEAKER 2. IN THE APP ❶ Connect your EF-IL speaker to your wifi network Press and hold Vol + and - ❷ Launch the E+F app. buttons for approx.. 3s until ❸ Tab device in the bottom menu bar. sound is heard.
PLAYING FROM SPOTIFY Use your phone, tablet or computer as a remote control for Spotify. Go to spotify.com/connect to learn how.
PLAYING FROM APPLE MUSIC USING AIRPLAY ❶ Launch the E+F app. ❷ Tap the Music tab. ❸ Tap Apple Music. ❹ Select a song, album, or playlist you want to listen to. ❺ Tap Play (or Play All). ❻ Tap the mini-player banner at the bottom of the screen. ❼ If it isn't already selected, tap your E+F speaker in the list. According to Apple regulations, you can only play music to one speaker at a time. Multiroom playback not possible with Airplay.
BLUETOOTH PAIR Source switch in E+F app Blue light flashing ❶Switch EF-IL to Bluetooth mode Press the source button to switch to Bluetooth Mode. EF-IL speaker will chime and the LED in front of the speaker will turn blue and flash. Optionally, E+F app also has the function to switch source to Bluetooth. ❷Pair your device with EF-IL speaker 1) Go to your device’s settings and turn on Bluetooth. 2) Select EF-IL speaker from the device list.
WiSA PAIR Green light flashing ❶Switch EF-IL to WiSA mode Press the source button to switch to WiSA Mode. EF-IL speaker will chime and the LED in front of the speaker will turn green and flash. ❷AEF Consoleor other WiSA certified Transmitters like the Axiim Link or the WiSA USB Transmitterwill find and connect EF-IL speaker seamlessly. For details please check the manual for the WiSA certified Transmitter.
USING ALEXA THROUGH THE APP 1.PressAmazoninsourceview. 2.Next,pressandholdtheAlexabuttonontheapp whilespeakingtoAlexain yourphone.When finished releasetheicon.Youwillhearanaudibletoneindicating Alexahasreceivedthemessageandshewill respond.
WIFI FAQ MY SPEAKER WILL NOT CONNECT TO MY NETWORK •Make sure your mobile device is connected to your wireless network before you try to connect your speaker. •Place the speaker close to the router when carrying out the setup. You can subsequently view the signal strength for other positions in the app. I GET THE MESSAGE “DEVICE CONNECTION FAILED” •Move the speaker closer to the router. •Make sure your mobile device is connected to the same network.
SPECIFICATIONS Type: Wireless multiroom speaker Amplifier: Digital Class D, 45 W Tweeter: 1 x 1" driver Woofer: 1 x 3", long throw Passive radiators: Dual 2 x 5" Frequency range: 55 – 20.000 Hz Crossover frequency: 2500 Hz Dimensions (H x W x D): EF-IL-T1: 521 x 318 x 318 mm Inputs: Wi-Fi, Bluetooth V5.0 Wireless network compatibility: IEEE 802.11 a/b/g/n/ac, 2.4 GHz / 5GHz Supported audio formats: MP3/AAC/FLAC/ALAC/WMA/APE/OGG codec Power consumption Wi-Fi/STBY/ON: 1.8 W-0.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage ”within the product ’ s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
FCC THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION ISSUBJECT TO THE FOLLOWING TWO CONDITIONS: 1 - THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. 2 - THIS DEVICE MUST ACCEPT INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIREDOPERATION. MODEL: EF-IL-D1 FCC WARNING Any Changes or modifications not expressly approved by the party responsible for compliance could void the user ’ s authority to operate the equipment. This device complies with part 15 of the FCC Rules.
