Model 248 Automotive Dynamometer Illustrated Parts List
1
Model 248 Overview
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MODEL 248 OVERVIEW
Models using the 248 Dyno:
1 81148200 248H GENERIC CAR DYNO, SEE PAGE 2
81148300 HIGH SPEED 248HS DYNO, SEE PAGE 3
2 81148400 HEAVY WIDE 248HW DYNO, SEE PAGE 4
248H-102 DYNOJET 48" HIGH INERTIA DYNO,
SEE PAGE 11
248HW-102 248 WIDE CAR DYNO SEE PAGE 13
448-4WD 248/248-4WD DYNAMOMETER,
SEE PAGE 13
Accessories
64111001 PROPORTIONAL AIR BRAKE, SEE PAGE 8
AD150
1
AD155
2
