ASSEMBLY INSTRUCTIONS DX-WD1201 Espresso TV Stand for 32" TVs Safety information and specifications ............2 Tools needed ............................................................3 Package contents ...................................................4 Assembly instructions...........................................
DX-WD1201 Safety information and specifications CAUTION: This stand’s work surface is intended only for use with a product not weighing more than 95 lbs. (43.09 kg) and accommodates most 32" flat-panel TVs with dimensions that will permit the TV to sit evenly on the stand. Using with other products, including products that weigh more than the maximum weight allowed, may result in instability, which may cause possible injury. Maximum weight: 95 lbs. (43.
DX-WD1201 3 Tools needed No.
DX-WD1201 Package contents Package contents: hardware Make sure you have all the hardware necessary to assemble your new TV stand: Label M2 Hardware Label Qty. Q 17 Hidden cam N2 Cam dowel 17 O Angle bracket 3 P Metal pin 6 Label Hardware Rubber sleeve Cam cover 13 S Warning label 1 Qty. 2 Black 1-7/8”flat head screw U 6 Black 9/16” large head screw V 24 Nail 1 10 20 2 30 40 50 4 R Hardware T Qty.
DX-WD1201 5 Package contents: parts Note: All parts except for the back (G) have a lettered sticker to make identifying parts easier. Letter Description Qty. Letter Description Qty.
DX-WD1201 Assembly instructions Step1: Assemble your stand on a carpeted floor or on the empty carton to avoid scratching your unit or the floor. A hidden cam (M2) has an arrow. When you insert the hidden cam, make sure that the arrow points toward the hole in the side of the part you are inserting it into. Push seventeen hidden cams (M2) into the ends (A and B), top (D), bottom (E), and shelf (F). Then, insert the metal end of a cam dowel (N2) into each hidden cam.
DX-WD1201 7 Tightening hidden cams: In the remaining steps, use these illustrations for instructions on tightening hidden cams. Warning: Risk of damage or injury. Hidden cams must be completely tightened. Hidden cams that are not completely tightened will loosen, and parts may separate. Arrow Make sure that you turn the hidden cam a minimum of 190° to a maximum of 210°. Note the position of the arrow on the hidden cam. Arrow 210° In the illustration below, the hidden cam has not been tightened enough.
DX-WD1201 Step 2: Fasten the shelf (F) to the ends (A and B). Use a Phillips screwdriver to tighten four hidden cams (M2). See “Tightening hidden cams:” on page 7. Insert two metal pins (P) into the upright (C), then insert the other ends of metal pins (P) into the holes in the shelf (F).
DX-WD1201 9 Step 3: Slide the bottom molding (K) onto the notched edge of the bottom (E). Fasten the bottom (E) to the ends (A and B). Use a Phillips screwdriver to tighten four hidden cams (M2). See “Tightening hidden cams:” on page 7. Fasten the bottom (E) to the upright (C). Use a Phillips screwdriver and two black 1-7/8" flat head screws (T).
DX-WD1201 Step 4: Fasten three angle brackets (O) to the stop molding (I). Use a Phillips screwdriver and three black 9/16" large head screws (U). Fasten the stop molding (I) to the top (D). Use a Phillips screwdriver to tighten three hidden cams (M2). See “Tightening hidden cams:” on page 7. Carefully turn your stand onto its top. Fasten the ends (A and B) to the top (D). Use a Phillips screwdriver to tighten six hidden cams (M2).
DX-WD1201 11 Step 5: Slide the end moldings (W) onto the notched edges of the ends (A and B). Fasten the top skirt (J) to the angle brackets (O) on the stop molding (I). Use a Phillips screwdriver and three black 9/16" large head screws (U). Note: There are no pre-drilled holes in the top skirt (J). The screws will tighten into the groove.
DX-WD1201 Step 6: Carefully turn your stand over onto its front edges. Unfold the back (G) and lay it over your stand. Make equal margins along the side and bottom edges of the back (G). Push on opposite corners of your stand if needed to make it “square.” Fasten the back (G) to your stand using the nails (V). Note: Make sure that you tap nails into the holes that line up over the upright (C) and shelf (F). Note: Perforations have been provided for access through the back (G).
DX-WD1201 13 Step 7: Carefully stand your stand upright. Push the rubber sleeves (Q) over the remaining metal pins (P). Insert the metal pins (P) into the hole locations of your choice in the right end (A) and upright (C). Set the adjustable shelf (H) onto the metal pins (P). Apply the warning label (S) to the top (D). You should be able to read the label when the TV is removed from your stand. When the TV is in place, it should hide the label. Peel off the backing and apply the label as shown.
DX-WD1201 Still need help? For customer service, call: 800-305-2204 (U.S./Canada markets) Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richfield, MN USA 55423-3645 © 2012 BBY Solutions, Inc. All rights reserved. DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
DX-WD1201 15 This page intentionally left blank.
Certificate of Conformity 1. This certificate applies to the Sauder Woodworking Product identified by this instruction booklet. 2. This certificate applies to the compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303). 3. This product was manufactured by: Sauder Woodworking Company 502 Middle Street Archbold, Ohio 43502 (419) 446-2711 4. Date of Manufacture: _________________ Lot number: 345973 www.dynexproducts.
