NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3
Return to the catalogue.
2
This gives users a low-cost, end-to-end solution and eliminates the need to train installation teams on multiple systems.
8 Ports 5/15/25M 4-Band VDSL IP DSLAM + 2 10/100/1000M Giga Ethernet
The 4-Band IP DSLAM has 8 x 5/15/25M VDSL ports and 2 x 10/100/1000M Ethernet ports. The IP DSLAM is one rack-unit
(1RU) high, 10-inches deep. It is a standard Rack mounted size.
4-Band IP DSLAM deliver dedicated bandwidth per port at rates of 5/15/25 Mbps. VDSL transmissions coexist with POTS
and ISDN, and can be compatible with ADSL/HomePNA traffic in the same building. The NVF-800Ses can be configured on
a
per-NVF-800S basis to support the following modes:
z 5 Mbps symmetrical rate (up to 1700 meters)
z 15 Mbps symmetrical rate (up to 1100 meters)
z 25 Mbps symmetrical rate (up to 600 meters)
The 4-Band VDSL IP DSLAM and 4-Band VDSL Modem provide fast and easy connectivity into building patch panels with
RJ-45 connector. The 10/100/1000 Giga Ethernet ports can be used to connect servers, Ethernet NVF-800Ses. These
connectivity options provide multiple price/performance options to meet building and budget requirements.
The 4-Band IP DSLAM provides the important features necessary for robust networks:
z Class of Service: 802.1p CoS support. Provides high-and low-priority queuing on a per-port basis.
z Supports: IGMP Snooping by 512 IP multicast table for VOD (Video on demand) and video conference and internet
games application.
z Scalability: Up to 5/15/25 Mbps symmetric performance over single-pair wiring. Fast Ether Channel
port aggregation.
z Security: 802.1Q Tagging-based and 802.1V protocol-based virtual local-area network (VLAN) support. Private VLAN
access, assuring port security without requiring a VLAN per port, and also supports MAC filtering.
