NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3
Return to the catalogue.
9
Product Specifications：
Compliant with IEEE 802.3 & 802.3u & 802.3ab Ethernet Standards
Compliant with ETSI, ITU, ANSI standards
10/100/1000Mbps Ethernet ports：2 x RJ-45 with auto crossover
POTS/ISDN Splitter port ： 8 x RJ-45
VDSL port ： 8 x RJ-45
MAC address table：8K Entries
Switching method ： Store-and-forward
Flow control method by IEEE802.3x for Full Duplex & Back Pressure for Half Duplex
Compliant with GARP/GVRP IEEE 802.1p/q port-base VLAN with 256 groups static VID or 4094 dynamic VID
Compliant with IEEE 802.1v protocol-base VLAN classification
Compliant with IEEE 802.1d Spanning trees
Multicast IP table ：512 groups
Compliant with IEEE 802.1p QOS by class of service with 2-level priority queuing
Compliant with LACP IEEE 802.3ad Trunking
RS-232 console port：DB-9Pin Female / 9600bps
SNMP v1 RFC-1493 Bridge MIBs
RFC-1643 Ethernet MIB
RFC-1213 MIB II
Enterprise MIBs
RMON groups 1(Statistics), 2(Alarm), 3(Event), 9(History)
Port security by MAC address filtering
