User`s manual

ManualsBrandsDynamix ManualsComputer equipment4-Band VDSL CO/CPE Modem

8VDSL +2 Giga Ethernet Managed 4-Band VDSL IP DSLAM

NVF-800S USER’S MANUAL

Best viewed at full screen.

Summary of content (84 pages)

PAGE 1
8VDSL +2 Giga Ethernet Managed 4-Band VDSL IP DSLAM NVF-800S USER’S MANUAL Best viewed at full screen.
PAGE 2
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 VDSL Solution The 4-Band VDSL IP DSLAM networking solution delivers cost-effective, high-performance broadband access to multiunit buildings (hotels, apartment, and multi-tenant unit office buildings) and enterprise campus environments such as manufacturing, educational campuses, and medical facilities.
PAGE 3
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 This gives users a low-cost, end-to-end solution and eliminates the need to train installation teams on multiple systems. 8 Ports 5/15/25M 4-Band VDSL IP DSLAM + 2 10/100/1000M Giga Ethernet The 4-Band IP DSLAM has 8 x 5/15/25M VDSL ports and 2 x 10/100/1000M Ethernet ports. The IP DSLAM is one rack-unit (1RU) high, 10-inches deep. It is a standard Rack mounted size. 4-Band IP DSLAM deliver dedicated bandwidth per port at rates of 5/15/25 Mbps.
PAGE 4
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 z z z z z z z z z z z In band Management : IP DSLAM provides a console port for setup IP or other function. Out of band Management: IP DSLAM supports remote control by Telnet and Web-based. Management easy-to-use configuration and ongoing monitoring. This software is embedded in the VDSL NVF-800S and delivers remote, intuitive management of IP DSLAM and connected VDSL CPE devices through a single IP address.
PAGE 5
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 z Supports multiple web browsers: IE, Mozilla & Netscape under Windows O/S Mozilla & Netscape under Linux O/S Contents 1. Unpacking Information Check List.........................................................6 Product Guide..................................................7 2. General Description Hardware Description......................................11 Front Panel ....................................................11 LED Indications ............
PAGE 6
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Appendix A: Troubleshooting................... ......66 Appendix B: VDSL Spectrum …………………69 Appendix C: Example of VLAN Setting ……..70 FCC/CE Mark Warning ………………………….82 Warranty ............................................................83 5 Return to the catalogue.
PAGE 7
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 1.Unpacking Information Check List Carefully unpack the package and check its contents against the checklist. Package Contents 1. NVF-800S 4-Band VDSL IP DSLAM 2 x10/100/1000 Giga Ethernet ports and 8 x 5/15/25Mbps VDSL ports 2. 1xUsers manual CD 3. 1xAC Power Cord 4. 2x Rack Mounting Brackets 5. 4x Screws 6. 4x Plastic feet Please inform your dealer immediately for any missing, or damaged parts.
PAGE 8
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Product Guide Product Name：2ports 10/100/1000Mbps Giga Ethernet plus 8ports 4-Band VDSL With SNMP Management IP DSLAM Application : Hotel/Campus/Hospitality/Telecom Features Supports 5M/15M/25Mbps per port symmetrical bandwidth over phone wiring with long driver capable1.7/1.1/0.6Km(5666/3666/1999 feet) with auto speed.
PAGE 9
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.
PAGE 10
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Product Specifications： Compliant with IEEE 802.3 & 802.3u & 802.3ab Ethernet Standards Compliant with ETSI, ITU, ANSI standards 10/100/1000Mbps Ethernet ports：2 x RJ-45 with auto crossover POTS/ISDN Splitter port ： 8 x RJ-45 VDSL port ： 8 x RJ-45 MAC address table：8K Entries Switching method ： Store-and-forward Flow control method by IEEE802.3x for Full Duplex & Back Pressure for Half Duplex Compliant with GARP/GVRP IEEE 802.
PAGE 11
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 LED indication：Power good and POST LED Link/Active/Speed Status for Ethernet port. Link for VDSL port. VDSL Frequency Spectrum： Transmitter ：0.9 ~ 3.9 MHz Receiver：4 ~ 7.9 MHz POTS/ISDN pass filter Spectrum : 0 ~ 630 kHz Internal Switching power adapter Input :AC 85-265 volts/50-60Hz/1A.
PAGE 12
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 2. General Description Hardware Description This section describes the important parts of the IP DSLAM. It features the front and rear panel drawings showing the LED, connectors, and NVF-800S. Front Panel The following figure shows the front panel. Figure Chapter 2.1 Front Panel description 11 Return to the catalogue.
PAGE 13
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Front panel. (1) “PWR”: Power Led light (2) “POST”: Power On Self Testing LED light (3) 2 X 10/100/1000 Mbps auto-negotiation Giga Ethernet ports (4) 8 X 5/15/25 Mbps VDSL Ports. (5) 8 X POTS/ISDN Splitter Ports. (6) RS-232 Console Port (7) Reset Button IP DSLAM has embedded Splitter between every VDSL side and POTS side. It permits you to deliver broadband service on the same lines as Plain Old Telephone Service (POTS), PBX, ISDN traffic and VDSL Signal.
PAGE 14
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 LED Indications The following describes the function of each LED indicator. LEDs Status Descriptions PWR Steady (Power LED) Green POST Steady VDSL Link Steady 10 LINK/ACT Steady Green Flashing Steady Green Flashing Steady Green Flashing 100 LINK/ACT 1000 LINK/ACT This LED light is located at the left side on the front panel. It will light up (ON) to show that the product is receiving power.
PAGE 15
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Rear Panel The following figure shows the rear panel Figure Chapter 2.3 Rear Panel AC Power Socket The power cord should be plug into this socket. The AC Socket accepts AC power 85 to 265 voltage. 1A. 14 Return to the catalogue.
PAGE 16
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 3.Installation Hardware Installation This chapter describes how to install the IP DSLAM. To established network connection. You may install the IP DSLAM on any level surface (table, shelf, 19 inch rack or wall mounting). However, please take note of the following minimum site requirements before you begin.
PAGE 17
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 General Rules Before making any connections to the IP DSLAM, note the following rules: Ethernet Port (RJ-45) All network connections to the IP DSLAM Ethernet port must be made using Category 5 UTP for 100Mbps and Category 3,4 UTP for 10Mbps. No more than 100 meters (about 328 feet) of cabling may be use between IP DSLAMs or with HUB or an end node. z VDSL Port (RJ-45) All home network connections to the VDSL Port made using 18 ~ 26 Gauge phone wiring.
PAGE 18
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 pair phone Line wiring with RJ-45 plugs at both ends. 3. Connect one end of the cable to the RJ-45 port of the Home Access network adapter, and the other end to any available (1~8) station port on the VDSL. Every port supports 5/15/25 Mbps connections. When inserting an RJ-45 plug, be sure the tab on the plug clicks into position to ensure that it is properly seated. ● Do not plug a RJ-11 phone jack connector into the Ethernet port (RJ-45 port).
PAGE 19
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 (Change IP Address By Terminal) You can configure the product with the local serial console port, If one of the RJ11 port is not in use, you can disable it, that procedure is to connect a notebook computer to the RS-232 port, then boot windows @95/98/ME/2000 system, and run “Hyper-terminal” program into terminal window, and setup step are as follow. 1. Set “Bits per second” at 9600 to the content window. 2. Set “Flow control” at None 3.
PAGE 20
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4. Operation Button: Tab=Next Item; BackSpace=Previous Item Enter=Select ItemSelect 5. Set IP Address: Please follow the following steps (1) Choose IP DSLAM Static Configuration you can enter next page 19 Return to the catalogue.
PAGE 21
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 (2) Choose Administration Configuration the you can enter next page Choose IP Configuration you can enter IP configuration page 20 Return to the catalogue.
PAGE 22
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 (3) a. Choose Edit item to Change IP address, Subnet Mask and Gateway b. Use CTRL+A button to back actions choice c. Choose Save item to save change and back to System Configuration page d. Choose Previous Menu item to quit System Configuration page e. Choose Main Menu item to quit IP DSLAM Configuration page and back to Main Manual f. Choose Reboot IP DSLAM item g. Choose Restart item to reboot your IP DSLAM. 21 Return to the catalogue.
PAGE 23
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2 Remote Network Management 4.2.1 IP Setting You must setup the “IP Address” with the local serial console port (RS-232 Port), and then you can use this IP address to control this VDSL IP DSLAM by Telnet and WEB. Or you can change your computer’s IP domain same with VDSL NVF-800S. Then use the default IP address to control this VDSL IP DSLAM. 1. Remote control by “Telnet” To enter Telnet, type the IP address of the IP DSLAM to connect management system.
PAGE 24
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2 Web Management Function 1. Provide a Web browser to manage and monitor the NVF-800S, the default values as follows: If you need change IP address in first time, you can use console mode to modify it. IP Address: 192.168.16.250 Subnet Mask: 255.255.255.0 Default Gateway: 192.168.16.1 User Name: admin Password: 123 2. You can browse http:// 192.168.16.250, type user name and password as above. 23 Return to the catalogue.
PAGE 25
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2-1. Web Management Home Overview This is VDSL Home Page. 4.2.2-2. Port status 1. This page can see every port status State: Display port status disable or enable, disable is unlink port, enable is link port.
PAGE 26
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Configure: Display the user setup, Actual: Display the negotiation result. Flow control: Display flow control status enable or disable mode User can see single port counter as following 25 Return to the catalogue.
PAGE 27
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2-3. Port Statistics 1. The following information provides a view of the current status of the unit. 26 Return to the catalogue.
PAGE 28
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2-4. Administrator There are many management function, include: IP Address NVF-800S Setting Port Controls Link Aggregation Filter Database VLAN Config. Spanning Tree Port Sniffer Snmp SNR Status Security Manager TFTP Update Firmware Configuration Backup Restart System Reboot 27 Return to the catalogue.
PAGE 29
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2-4-1. IP Address 1. User can configure the IP Settings and fill in the new value, than clicks apply button. 2. User must be reset NVF-800S and use new IP address to browser this web management. Default IP is 192.168.16.250 28 Return to the catalogue.
PAGE 30
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2-4-2. IP DSLAM Setting 2-4-2-1.Basic 1. Description: Display the device type of name. 2. MAC Address: The unique hardware address assigned by manufacturer 3. Firmware Version: Display the IP DSLAM’s firmware version. 4. Hardware Version: Display the IP DSLAM’s Hardware version. 5. Default config value version: Display write to default EEPROM value tale version. 29 Return to the catalogue.
PAGE 31
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 2-4-2-2.Advanceed Miscellaneous Setting: MAC Address Age-out Time: Type the number of seconds that an inactive MAC address remains in the NVF-800S' address table. The valid range is 300~765 seconds. Default is 300 seconds. Max bridge transit delay bound control: Limit the packets queuing time in NVF-800S. If enable, the packets queued exceed will be drop. This valid value are 1sec, 2 sec, 4 sec and off. Default is 2 seconds.
PAGE 32
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Priority Queue Service settings: First Come First Service: The sequence of packets sent is depend on arrive order. All High before Low: The high priority packets sent before low priority packets. Weighted Round Robin: Select the preference given to packets in the NVF-800S' high-priority queue. These options represent the number of high priority packets sent before one low priority packet is sent.
PAGE 33
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Protocol Enable Setting: Enable Spanning Tree Protocol: Default recommend to enable STP Enable Internet Group Multicast Protocol: enable IGMP protocol VLAN Protocol: 802.1Q(Tagging Based) without GVRP VLAN mode 802.1Q(Tagging Based) with GVRP VLAN mode 32 Return to the catalogue.
PAGE 34
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 GVRP (GARP [Generic Attribute Registration Protocol] VLAN Registration Protocol) GVRP allows automatic VLAN configuration between the NVF-800S and nodes. If the NVF-800S is connected to a device with GVRP enabled, you can send a GVRP request using the VID of a VLAN defined on the NVF-800S, the NVF-800S will automatically add that device to the existing VLAN.
PAGE 35
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 than Minimum value, VDSL speed will decrease. Priority of Minimum setup is higher than Maximum setup. £ 4.2.2-4-3. Console Port Information 1. Console is a standard UART interface to communicate with Serial Port. User can use windows HyperTerminal program to link the NVF-800S. Connect To->Configure Bits per seconds: 9600 Data bits: 8 34 Return to the catalogue.
PAGE 36
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Parity: none STOP BITS: 1 Flow control: none 4.2.2-4-4. VDSL Speed Control and port Enable/Disable This section shows you how to change every port status and speed mode State: You can disable or enable VDSL port control Auto Negotiation: You can set enable or disable VDSL port Speed: You can change VDSL Speed mode by 5Mbps, 15Mbps or 25Mbps Speed Default Value: Auto-speed Distance between VDSL & VDSL modem when standard 24 Gauge 0.
PAGE 37
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 If fail, auto-speed down to 5M and keep this mode then re-link with NVF-200R e. Please note any length of phone cable change, NVF-200R must re-power again, due to auto-speed function only work on re-starting. f. Await 5 ~ 120 seconds until VDSL port link up with depend on length of phone cable.
PAGE 38
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 The Link Aggregation Control Protocol (LACP) provides a standardized means for exchanging information between Partner Systems on a link to allow their Link Aggregation Control instances to reach agreement on the identity of the Link Aggregation Group to which the link belongs, move the link to that Link Aggregation Group, and enable its transmission and reception functions in an orderly manner.
PAGE 39
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 2.LACP: If enable, the group is LACP static trunking group. If disable, the group is local static trunking group. All ports support LACP dynamic trunking group. If connecting to the device that also supports LACP, the LACP dynamic trunking group will be created automatically. 3. Work ports: The max number of ports can be aggregated at the same time. If LACP static trunking group, the exceed ports is standby and able to aggregate if work ports fail.
PAGE 40
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Active (select): The port automatically sends LACP protocol packets. Passive (no select): The port does not automatically sends LACP protocol packets, and responds only if it receives LACP protocol packets from the opposite device. 1. A link having either two active LACP ports or one active port can perform dynamic LACP trunking.
PAGE 41
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2-4-6. Filter Database 2-4-6-1. IGMP Snooping The IP DSLAM support IP multicast, you can enable IGMP protocol on web management’s NVF-800S setting advanced page, then display the IGMP snooping information in this page, you can view difference multicast group, VID and member port in here, IP multicast addresses range from 224.0.0.0 through 239.255.255.255.
PAGE 42
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 IGMP have three fundamental types of message as follows: Message Query Report Leave Group Description A message sent from the queries (IGMP router or NVF-800S) asking for a response from each host belonging to the multicast group. A message sent by a host to the queries to indicate that the host wants to be or is a member of a given group indicated in the report message.
PAGE 43
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 2-4-6-2. Static MAC Address When you add a static MAC address, it remains in the NVF-800S' address table, regardless of whether the device is physically connected to the NVF-800S. This saves the NVF-800S from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again. 1. To add a static MAC address 2. From the main menu, click administrator, then click Filter Database. 3.
PAGE 44
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 2-4-6-3. Port Security A port in security mode will be “locked” without permission of address learning. Only the incoming packets with SMAC already existing in the address table can be forwarded normally. User can disable the port from learning any new MAC addresses, then use the static MAC addresses screen to define a list of MAC addresses that can use the secure port. Enter the settings, then click Submit to apply the changes on this page.
PAGE 45
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 2-4-6-4. MAC filtering MAC address filtering allows the NVF-800S to drop unwanted traffic. Traffic is filtered based on the destination addresses. For example, if your network is congested because of high utilization from one MAC address, you can filter all traffic transmitted from that MAC address, restoring network flow while you troubleshoot the problem. 44 Return to the catalogue.
PAGE 46
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2-4-7. VLAN configuration A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain. It allows you to isolate network traffic so only members of the VLAN receive traffic from the same VLAN members. Basically, creating a VLAN from a NVF-800S is logically equivalent of reconnecting a group of network devices to another Layer 2 NVF-800S. However, all the network devices are still plug into the same NVF-800S physically.
PAGE 47
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Support Protocol-based VLAN In order for an end station to send packets to different VLAN, it itself has to be either capable of tagging packets it sends with VLAN tags or attached to a VLAN-aware bridge that is capable of classifying and tagging the packet with different VLAN ID based on not only default PVID but also other information about the packet, such as the protocol.
PAGE 48
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 2-4-7-1. Basic Create a VLAN and add tagged member ports to it. 1. From the main menu, click administrator -- VLAN configuration. 2. Click “Add” 3. Type a name for the new VLAN. 4. Type a VID (between 2-4094). The default is 1. 5. From the Available ports box, select ports to add to the NVF-800S and click Add. 6. Click “Apply”. 47 Return to the catalogue.
PAGE 49
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 2-4-7-2. Port VID Configure port VID settings From the main Tag-based (IEEE 802.1Q) VLAN page, click Port VID Settings. Port VID (PVID) Sets the Port VLAN ID that will be assigned to untagged traffic on a given port. For example, if port 10's Default PVID is 100, all untagged packets on port 10 will belong to VLAN 100. The default setting for all ports is VID 1.
PAGE 50
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Ingress Filtering Ingress filtering lets frames belonging to a specific VLAN to be forwarded if the port belongs to that VLAN. IP DSLAM has two ingress filtering rule as follows: Ingress Filtering Rule 1:Forward only packets with VID matching this port's configured VID Ingress Filtering Rule 2:Drop Untagged Frame 49 Return to the catalogue.
PAGE 51
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2-4-8. Spanning Tree The Spanning-Tree Protocol (STP) is a standardized method (IEEE 802.1D ) for avoiding loops in NVF-800S networks. When STP enabled, to ensure that only one path at a time is active between any two nodes on the network. You can enable Spanning-Tree Protocol on web management’s NVF-800S setting advanced item, select enable Spanning-Tree protocol.
PAGE 52
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 3. You can set new value for STP parameter, then click set Apply button to modify. Parameter Priority Max Age Hello Time Forward Delay time Description You can change priority value, A value used to identify the root bridge. The bridge with the lowest value has the highest priority and is selected as the root. Enter a number 1 through 65535. You can change Max Age value, The number of seconds a bridge waits without receiving.
PAGE 53
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 forwarding state. Enter a number 4 through 30. 4. The following parameter can be configured on each port , click set Apply button to modify . Parameter Description You can make it more or less likely to become the root port, the rage is 0-255,default setting is 128 the lowest Port Priority number has the highest priority. If you change the value, you must reboot the NVF-800S.
PAGE 54
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2-4-9. Port Sniffer The Port Sniffer is a method for monitor traffic in NVF-800S networks. Traffic through ports can be monitored by one specific port. That is, traffic goes in or out monitored ports will be duplicated into sniffer port. Roving Analysis State: Enable or disable the port sniffer function. Analysis Port: Analysis port can be used to see all monitor port traffic. You can connect sniffer port to LAN Analysis, Session Wall or Netxray.
PAGE 55
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2-4-10. SNMP Any Network Management running the Simple Network Management Protocol (SNMP) can management the NVF-800S, Provided the Management Information Base (MIB) is installed correctly on the management station. The SNMP is a Protocol that governs the transfer of information between management and agent. The VDSL NVF-800S support SNMP V1. 1. Use this page to define management stations as trap managers and to enter SNMP community strings.
PAGE 56
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 2. Community strings serve as passwords and can be entered as one of the following: Read only: Enables requests accompanied by this string to display MIB-object information. Read write: Enables requests accompanied by this string to display MIB-object information and to set MIB objects. 55 Return to the catalogue.
PAGE 57
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 3. Trap Manager A trap manager is a management station that receives traps, the system alerts generated by the NVF-800S. If no trap manager is defined, no traps are issued. Create a trap manager by entering the IP address of the station and a community string. Enterprise MIB contains two traps: a. When IP DSLAM internal temperature is greater than 70℃, system will send a “Temperature alarm “ trap. b.
PAGE 58
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 4.2.2-4-12 Security Manager 1. Use this page; user can change web management user name and password. User name: Admin 57 Return to the catalogue.
PAGE 59
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Password: 123 4.2.2-4-13. TFTP Update Firmware 1. The following menu options provide some system control functions to allow a user to update firmware and remote boot NVF-800S system: * Install TFTP Turbo98 and execution. * Copy firmware update version image.bin to TFTP Turbo98 directory. * In web management select administrator—TFTP update firmware. * Download new image.bin file then in web management press . 4.2.2-4-14.
PAGE 60
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Use this page to set TFTP server address. You can restore EEPROM value from here, but you must put back image in TFTP server, the NVF-800S will download back the flash image. 2-4-13-2. TFTP Backup Configuration Use this page to set TFTP server IP address. You can save current EEPROM value from here, then go to the TFTP restore configuration page to restore the EEPROM value. 4.2.2-4-15.
PAGE 61
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Note. Please make sure the IP DSLAM has been disconnected with VDSL Modem 4.2.2-4-16. Reboot Reboot the IP DSLAM in software reset 5. Applications 60 Return to the catalogue.
PAGE 62
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 The VDSL provides home network architecture. Transforming an apartment into a Multiple-Family Home network area, sharing a single internet account for multiple users via Router & Cable Modem, it can provide unlimited access time in the internet at a reasonable low price. Bridging Functions – The IP DSLAM provides full transparent bridging function.
PAGE 63
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 *Application for Video on demand and Video conference 62 Return to the catalogue.
PAGE 64
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Used as apartment for Internet access The IP DSLAM provides a high speed, auto-speed transmission over existing home telephone wiring over a single Internet account to provide simultaneous independent Internet access to multiple users. No matter ISDN Telephone system nor POTS Telephone system you have, the VDSL Technology let you can use the telephone system and VDSL network system in the same time. 63 Return to the catalogue.
PAGE 65
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Figure Chapter 4.1 Application for Sharing a single internet account If multiple users would like to share a single internet account using the IP DSLAM, which is to be connected to a IP sharing device, then to a xDSL or Cable Modem. 64 Return to the catalogue.
PAGE 66
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Note: For network applications that actually require Router (e.g., Interconnecting dissimilar network types), attaching the IP DSLAM directly to a router can significantly improve overall home networking performance. High bandwidth backbone ready The IP DSLAM provides 10/100/1000Mbps auto sensing for external trunk device (Fiber optics, Wireless Bridge, xDSL & other WAN services) 65 Return to the catalogue.
PAGE 67
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Appendix A: Troubleshooting Diagnosing VDSL Indicators The VDSL can be easily monitored through its comprehensive panel indicators. These indicators assist the network manager in identifying problems the IP DSLAM may encounter. This section describes common problems you may encounter and possible solutions 1. Symptom: POWER indicator does not light up (green) after power on.
PAGE 68
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 System Diagnostics Power and Cooling Problems If the POWER indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply as explained in the previous section.
PAGE 69
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Cabling 1. Verify that the cable type is correct. Be sure RJ-45 cable connectors are securely seated in the required ports. Use 100Ω straight-through cables for all standard connections. Use Category 5 cable for 100/1000Mbps Fast Ethernet connections, or Category 3, 4 or 5 cables for standard 10Mbps Ethernet connections. Be sure RJ-45 phone wiring, use 18~26 gauge. 2. Make sure all devices are connected to the network.
PAGE 70
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Appendix B: VDSL Spectrum VDSL Technology – Requirements & Definitions Spectral Allocation • Co-exists with legacy Voice and ISDN services Slide 5 06-April-2000 page: 5 • Co-exists with other xDSL technologies • Programmable notch filter to avoid Radio Frequency Interference  2002 Infineon Technologies COM/AC All rights reserved VDSL Spectral Allocation 69 Return to the catalogue.
PAGE 71
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Appendix C: Example of VLAN Setting 1. Port_Based VLAN Setting Web management Æ Administrator Æ NVF-800S settings Æ Advanced: Protocol Enable SettingÆ VLAN Operation Mode: Select “Port_Based” 70 Return to the catalogue.
PAGE 72
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Web management Æ Administrator Æ NVF-800S settingsÆVlan Configuration: 71 Return to the catalogue.
PAGE 73
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Add VLAN Group 1, member: port 1 and port 9 72 Return to the catalogue.
PAGE 74
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 2. Tag_Based (IEEE 802.1Q) VLAN Setting Web management Æ Administrator Æ NVF-800S settings Æ Advanced: Protocol Enable SettingÆ VLAN Operation Mode: Select “802.1Q without GVRP” 73 Return to the catalogue.
PAGE 75
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Administrator Æ VLAN Configuration: Select “Port VID” in this stage, you can define each port’s PVID and set traffic rules for each port. Note: There are two basic rules for setting traffic filtering rule while you use Tag VLAN. 1. Ingress rule will be taking effect when the packet is "incoming" packet. 2. Ingress rule 1 and 2 will be checked when you use tag. Otherwise the ingress rule will be meaningless. 74 Return to the catalogue.
PAGE 76
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 VLAN Configuration: Select “Basic” • Default_1 exists when you use 802.1Q Tag VLAN. • Highlight default_1 and click Edit button to add/remove each port. 75 Return to the catalogue.
PAGE 77
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 In default_1 group, add in or remove group members. Click Next button to set Tag or Untag for each assigned port. 76 Return to the catalogue.
PAGE 78
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 From this page, you can set Tag or Untag for assigned port and click Apply button. 77 Return to the catalogue.
PAGE 79
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Add in new group. • Click Add button into new group setting page. 78 Return to the catalogue.
PAGE 80
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Add in new group page. • Fill in new group name into VLAN Name. • Set the VID number. • Add in new group members. • Click Next button. 79 Return to the catalogue.
PAGE 81
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 Set Tag or Untag for group members and click Apply button. 80 Return to the catalogue.
PAGE 82
NVF-800S 4-Band VDSL IP DSLAM USER’S MANUAL Ver.A.3 New group has been created, now you can highlight each group and click Edit or Delete button to modify or delete VLAN Group. 81 Return to the catalogue.
