ADSL Router User Manual
Rear Panel
The following figure illustrates the rear panel of your ADSL Router:
Connector Description
DSL
RJ-11 connector
USB
USB connector
Ethernet
Ethernet RJ-45 connector
Power switch
9VAC
9VAC Power connector
Note: For use only with power supply HON-KWANG type A9100-230, Leader
type A41090100.
