www.ghpgroupinc.com.

RMC-LPC25DG/DGD/DGP/DGP-01 & LPC25 (PROPANE, 25,000 BTU/hr)

RMC-LPC80DG/DGD/DGP/DGP-01 (PROPANE, 80,000 BTU/hr)

RMC-LPC80C/L/L-01 (PROPANE, 80,000 BTU/hr)

RMC-LPC200L/DG/DGP/DGP-01 (PROPANE, 200,000 BTU/hr)

4:30 service department at 877-447-4768 pm CST, Monday – Friday

Questions, problems, missing parts? Before returning to your retailer, call our customer

8:30 a.m. –

or email us at customerservice@ghpgroupinc.com

www.ghpgroupinc.com

C US

GHP Group, Inc.

6440 W Howard St

Niles, IL 60714-3302

ANS Z83.7-2011 CSA 2.14-2011

Adequate ventilation must be provided.

Propane Construction Heater

IMLPCDG - KCA

WARNING

This product and the fuels used to operate this product (liquid propane), and the products of combustion

of such fuels, can expose you to chemicals including benzene, which is known to the State of California to

cause cancer and reproductive harm.

For more information go to www.p65Warnings.ca.gov

Summary of content (14 pages)

PAGE 1
Propane Construction Heater RMC-LPC25DG/DGD/DGP/DGP-01 & LPC25 RMC-LPC80DG/DGD/DGP/DGP-01 RMC-LPC80C/L/L-01 RMC-LPC200L/DG/DGP/DGP-01 C (PROPANE, 25,000 BTU/hr) (PROPANE, 80,000 BTU/hr) (PROPANE, 80,000 BTU/hr) (PROPANE, 200,000 BTU/hr) US ANS Z83.7-2011 CSA 2.14-2011 Adequate ventilation must be provided. GHP Group, Inc.
PAGE 2
PAGE 3
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! RMC-LPC25Series / RMC-LPC80 Series.................................. RMC-LPC200 Series............... Illustration RMC-LPC25 Series.................................................................... Illustration RMC-LPC80 Series................................................................... Illustration RMC-LPC200 Series.................................................................
PAGE 4
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! (lb/h) Minimum Maximum Maximum Minimum LPC25 Series 1.16 0.7 (0.32 kg/h) (0.53 kg/h) .196 11.7 x 12.87 (4.98 mm) (29.69 x 32.79 cm) LPC80 Series 3.71 2.32 (1.05 kg/h) (1.68 kg/h) .196 15.9 x 18.3 (4.98 mm) (40.41 x 46.99 cm) LPC200 Series 9.28 2.32 (1.05 kg/h) (4.21 kg/h) .196 15.9 x 26.2 (4.98 mm) (40.41 x 66.49 cm) The heater is designed for use as a construction heater in accordance with ANSI Z83.7, CSA 2.14.
PAGE 5
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! (100 lb.) 60 °F (15.56 °C) 40 °F (4.44 °C) 32 °F (0 °C) 20 °F (-6.67 °C) 10 °F (-12.22 °C) 0 °F (-17.78 °C) Use this heater only with a propane vapor withdrawal supply system. Installation must conform to local codes or, in the absence of local codes, with the standard for the Storage and Handling of Liquefied Petroleum Gases ANSI/NFPA 58 and the Natural Gas and Propane Installation Code CSA B149.1.
PAGE 6
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Assembly Time: 10 minutes Contents All Models: Unit, Manual, Hose and Regulator Assembly LPC80 and 200 Series Include: Upper Shell, Lower Shell and Hardware Kit With Screws (8) Tools Required for Assembly All Models: Adjustable Wrench LPC80 and LPC200 Series: Phillips head screwdriver Slide upper shell assembly up and off lower shell. For Technical Support or Troubleshooting, Call: 1-877-447-4768 www.ghpgroupinc.
PAGE 7
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 10 11. Check all connections for leaks. Apply mixture of liqud soap and water to gas joints. Bubbles forming show a leak that must be corrected before using the heater. ( ) Turn propane supply valve on by turning tank valve counterclockwise . ( ) 6. If flame burner goes out, wait 5 minutes then repeat steps 4 and 5. Turn propane supply valve off by turning fully clockwise . For Technical Support or Troubleshooting, Call: 1-877-447-4768 www.ghpgroupinc.
PAGE 8
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Fully open the valve on the propane cylinder counter clockwise and wait 15 seconds before proceeding to step 2. RMC-LPC25/80/200 Propane Convection Heater gap is .196” (4.98 mm). Check wire lead for damage. For Technical Support or Troubleshooting, Call: 1-877-447-4768 www.ghpgroupinc.
PAGE 9
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Store propane tank(s) in safe manner. Refer to Chapter 5 of Standard for Storage and handling of Liquefied Petroleum Gases, ANSI/NFPA 58, and the Natural Gas and Propane Installation Code CSA B149.1. Follow all local codes. Always store propane tanks outdoors. Warning: Use only original replacement parts. This Heater must use design-specific parts. Do not substitute or use generic parts. Improper replacement parts could cause serious or fatal injuries.
PAGE 10
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Replacement Parts for RMC-LPC25 Series GS22-LPC25 J Regulator & Hose Assy 10’ (3.05 m) Regulator & Hose Assy 15’ (4.57 m) For Technical Support or Troubleshooting, Call: 1-877-447-4768 KR10601-10-31 KR10601-15-31 www.ghpgroupinc.
PAGE 11
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Replacement Parts for RMC-LPC80 Series GS22-LPC80 Regulator & Hose Assy 10’ (3.05 m) Regulator & Hose Assy 15’ (4.57 m) For Technical Support or Troubleshooting, Call: 1-877-447-4768 GR109-10-31 GR109-15-31 www.ghpgroupinc.
PAGE 12
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Replacement Parts for RMC-LPC200 Series GQ01 Regulator & Hose Assy 10’ (3.05 m) Regulator & Hose Assy 15’ (4.57 m) For Technical Support or Troubleshooting, Call: 1-877-447-4768 GS16 GR108-10-25 GR108-15-25 www.ghpgroupinc.
PAGE 13
Warranty LIMITED WARRANTY: This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any defect in materials and workmanship for a period of one (1) year from the date of retail sale (lifetime warranty for the brass nozzle burner only). GHP Group, Inc.
PAGE 14
WARRANTY REGISTRATION IMPORTANT: We urge you to fill out your warranty registration card within fourteen (14) days of date of purchase. You can also register your warranty on the internet at www.ghpgroupinc.com. Complete the entire serial number. Retain this portion of the card for your records. GHP Group, Inc. 6440 W Howard St Niles, IL 60714-3302 Tel: (877) 447-4768 www.ghpgroupinc.com SAVE THIS CARD! Place Postage Stamp Here GHP Group, Inc.
