iPhone 6 Power Case.
iPhone 6 Power Case.
Table of contents Table of Contents: Product Introduction................................................................................................ 4 Product Description............................................................................................ 4 Product Features................................................................................................ 4 Package Contents..............................................................................................
PRODUCT Introduction Product Description The Dyconn i6 Power Case is a durable and powerful 3200 mAh battery case that extends the battery life of your iPhone 6 by 130%, affording extra time to browse the web, take photographs, listen to music or enjoy your favorite app. The Dyconn i6 Power Case provides full-phone protection with a strong polycarbonate construction design, while built-In LED status indicators illuminate to show the amount of charge left within the I6 Power Case.
PRODUCT SPECIFICATIONS/Maintenance Specifications: Battery Type: Li-Polymer Capacity: 3.7V/3200mAh Input: DC 5V/1A (Max) Output: DC 5V/1A (Max) Dimensions: 6” x 2.75” x .5” (153 x 70 x 14mm) Weight: 3.1 oz.(88g) Charging Time: 3.5 Hours Output Interface: Lightning Input Interface: Micro Charging Cable: Micro USB Care and Maintenance: The Dyconn i6 Power Case should be treated with care during use and storage. As such, please follow the suggested maintenance advice below: 1.
PRODUCT Introduction i6 Power Case Diagram The diagram below shows the various features and functional parts of the Dyconn i6 Power Case. iPhone Power Mute Camera Hole Volume+/- iPhone Connector Speaker Power Indicator Power Switch Headset Micro Input Touch i6 Power Case FAQ 1. I cannot charge iPhone and power case together. Solution: Make sure the data line is connected properly. 2. I cannot charge after pressed power switch.
PRODUCT assembly Instructions Assembling and Dissembling the i6 Power Case Assembling: 1. Place the Dyconn i6 Power Case on a hard and even surface. Proceed to slide the iPhone into the case, starting with the lower portion of the phone (Diagram 1). Next, Push the phone downward while working the case’s rubber liner around the top-edge of the iPhone (Diagram 2). 1 2 Disassembling: 2.
charging the i6 power case Charging the Power Case with PC and AC Power Source 1. Connect the iPhone 6 Power Case to the AC Power Adapter using the Micro USB Cable. LED power indicators will commence to flash during the charging process. When the Power Case is fully charged, all LED power indicators will illuminate. 2.
charging the iphone 6 Charging the iPhone 6 1. After the iPhone is installed into the Power Case. Proceed to press the Power Button for 2 seconds. The Power Case will automatically charge and the LED power indicators will turn off after 5-seconds. To cancel the charging process, press the Power Button for 2 seconds. Note: Please make sure there is enough power inside the Power Case before charging the iPhone. Checking the iPhone 6 Battery Level 1.
wirelessly charging the i6 Power Case Wireless Charging the i6 Power Case Charging the Dyconn i6 Power Case can also be achieved with use of the Power Case Charging Dock (Sold Separately). 1. Please note the Dyconn i6 Power Case can be wirelessly charged while the phone is On or Off. You can either turn the phone Off or keep the phone On. 2. To charge the Dyconn i6 Power Case, connect the Charging Dock to an AC power adapter or PC/MAC USB port using the provided Micro USB Cable.
dyconn limited warranty DYCONN warrants only to the original purchaser of this product from a Dyconn-authorized reseller or distributor that this product will be free from defects in material and workmanship under normal use and service for (1) one-year after date of purchase. Purchaser must present acceptable proof of original ownership (such as original receipt, warranty card registration, on-line registration, or other documentation Dyconn deems acceptable) for the product.
iPhone 6 Power Case.
