Owner's manual

A1LP Alarm 1 Lamp: Select O on or O oFF. Factory default is O on.
O on Alarm Lamp is ON when alarm contact is closed.
OoFF Alarm Lamp is OFF when alarm contact is closed.
AL2 Alarm 2 function: Select OFF, L o, Hi, or H i L o. Factory default is Lo.
OFF Alarm 2 is disabled. No Alarm 2 menu items appear in the
Secondary or Secure menus.
Lo Low Alarm Only. A2Lo appears in the Secondary Menu.
Hi High Alarm Only. A2Hi appears in the Secondary Menu.
HiLo High and Low Alarms. Both A2Lo and A2Hi appear in the
Secondary Menu, and share the same Alarm 2 Relay output.
If AL2 is set to OFFthe remaining A2, alarm 2, menu items do not appear.
A2t Alarm 2 Type: Select AbS or dE. Factory default is A b S .
AbS Absolute Alarm that may be set anywhere within the values of
SCALand S C A H and is independent of SP1H.
dE Deviation Alarm that may be set as an offset from S P 1H. As S P1H
is changed the Alarm Point will track with SP1H.
A2rE Alarm 2 Reset: Select OnOF or Hold . Factory default is O n OF.
OnOF Automatic Reset.
Hold Manual Reset. Reset (acknowledge) by simultaneously pressing
the INDEX & DOWN ARROW keys for 5 seconds.
A2Pi Alarm 2 Power Interrupt: Select On or OFF. Factory default is O F F.
On Alarm Power Interrupt is ON.
OFF Alarm Power Interrupt is OFF.
A2 iH Alarm 2 Inhibit: Select O n or OFF. Factory default is O F F.
On Alarm Inhibit is On. Alarm action is suspended until the process
value first enters a non-alarm condition.
OFF Alarm Inhibit is OFF.
A2St Alarm 2 Output State: Select C LOS or OPEn. Factory default is C L OS.
CLOS Closes Contacts at Alarm Set Point.
OPEn Opens Contacts at Alarm Set Point.
A2LP Alarm 2 Lamp: Select O on or O oFF. Factory default is O on.
O on Alarm Lamp is ON when alarm contact is closed.
OoFF Alarm Lamp is OFF when alarm contact is closed.
19
