Lambda 131 HS Large Format Digital Laser Imager The evolution in imaging to unsurpassed large-format quality: from images, graphics and text direct on to conventional photomaterial via a file.
3 Models to meet your Requirements Lambda 131 HS-Turret The Lambda 131 is the top of the line version featuring a 5-position paper turret for the unexposed media (paper, backlit, clear film, flex media) or different media widths or surfaces from 50.8 cm (20 in.) up to 127 cm (50 in.). This allows very fast access to the required media without the need to physically load and unload it. You can handle mixed orders or calibrate a new emulsion without slowing down or interrupting production.
5-position paper turret for unexposed materials to allow a quick access to various media. Patented Durst Lambda continuous roll to roll single beam, 3-laser (RGB) exposure system.
The Key Features Direct digital printing with unsurpassed image and text quality Durst Lambda Series combine the advantages of classical silver halide photography with the potential of the latest laser and digital technology, without an intermediate film stage - and without the compromises of CMYK output, This technology offers superior color saturation and fidelity, better image quality, more details and sharper type than other alternatives (customer statement).
Software Features On-the-fly Image Processing Proprietary Linux-based Durst user software with patented on-the-fly image processing for very fast and reliable production with minimum hard disk usage (on-the-fly pixel interpolation/scaling, color, density, contrast, saturation and sharpening corrections, color to black and white conversion, cropping, etc.).
Flexibility and Productivity Paneling/Tiling Feature Print sizes exceeding the maximum paper width are automatically divided into strips and exposed with cut marks. This automatic tiling includes the following options: • division to match paper width • all the panels with the same width • direct input of a required panel width (custom panel width) • direct input of a required panel length The exact panel setting can then be modified as needed by the user. The required overlap can be set.
Image cropping Any part of the image can be crop-enlarged without postprocessing. A special interpolation procedure recalculates and generates the pixels involved, and so substantially enhances the image quality in comparison to conventional enlargements.
Technical Data General specifications Power Supply: 230/208 V AC ±10 %, single phase, 50/60 Cycles Power Consumption: max. 1500 VA/6 Ampere per phase Dimensions: Width: approx. 240 cm (95 in.) Length: approx. 240 cm (95 in.) Height: Lambda 131 HS-Turret: approx. 194 cm (77 in.) Lambda 131 HS: approx. 180 cm (71 in.) Weight: Lambda 131 HS-Turret: approx. 1.500 kg (3.300 lb.) Lambda 131 HS: approx. 1400 kg (3080 lb.) Space requirement: approx. 4 x 5 m (13 x 16 ft.
