18
Choosing the Right Power Cord
Long or thin cords can drain the power provided to an electrical device by the generator.
When using such cords, allow for a slightly higher rated wattage requirement for the
electrical device. See Figure 12 for recommended cords based on the power
requirement of the electrical device.
DEVICE REQUIREMENTS
WIRE GAUGE BY LENGTH (ft.)
AMPS
WATTS (120V/240V)
10
25
50
100
150
5
600/1200
18
16
14
12
10
10
1200/2400
16
14
12
10
8
15
1800/3600
14
12
10
8
6
20
2400/4800
12
10
8
6
4
25
3000/6000
10
8
6
4
4
30
3600/7200
8
6
4
4
NR
40
4800/9600
6
4
4
NR
NR
50
6000/1200
4
4
2
NR
NR
*NR = NOT RECOMMENDED
Figure 12 – Minimum Extension Cord Requirements
DC Usage
CAUTION: The DC receptacle is for recharging 12 Volt automotive-type batteries
only. Do not connect any other device to this receptacle.
CAUTION: Never try to jump start a car with your generator.
To connect a 12V battery to the DC battery charger on the front panel:
1. Connect one charging wire to the positive terminal on the battery and the other
charging wire to the negative terminal on the battery.
2. Connect the free end of the positive wire to the positive receptacle (outlet) on the
generator.
3. Start the generator.
4. Carefully connect the free end of the negative wire to the negative receptacle on
the generator.
5. When disconnecting, always disconnect the wires from the generator first to
avoid a spark.
DANGER: Stored batteries emit highly explosive hydrogen gas when charged.
Batteries also contain acid, which can cause severe chemical burns.
Do not allow open flames or cigarettes nearby for several minutes after charging a
battery.
Always wear protective goggles and rubber gloves when charging a battery.
If battery acid gets on your skin, flush with water.
If battery acid gets in your eyes, flush with water and call a physician immediately.
If battery acid is swallowed, drink large quantities of milk and call a Physician
immediately.
If your generator is the electric start model, once running, it will charge the battery on the
generator automatically. While charging, you can see the recharge indicator light lit, after
the battery is full, the light will turn off.
