Operation Manual

2.2 Elements on the Frame
Element Function
Frame Type MG 55-3
1 Main switch - Switching the machine on and off
2 Pedal
Rest position - No function
Position forward - Sewing with desired rpm
Position "half back" - Raise pressure foot when machine at rest
Position "full back" - Thread trimming and raise pressure foot
3 Screw - Setting the Table Top Height.
Frame Type MG 56-2
4 Main switch - Switching the machine on and off
5 Pedal
Rest position - No function
Position forward - Sewing with desired rpm
Position "half back" - Raise pressure foot when machine at rest
Position "full back" - Thread trimming and raise pressure foot
6 Lever - Securing the raised table top half
7 Brace - For supporting the lowered table top in the
horizontal position.
