Software settings
Operating Instructions 581 - 00.0 - 02/201594
Selecting a buttonhole
To select a buttonhole:
Step
1. Select the buttonhole within the sequence shown using the
keys or .
The desired buttonhole is marked with a bar.
As a selection aid, the current buttonhole shape is displayed
in the Buttonhole shape (1) field and the corresponding
values are displayed in the Values (2) area.
Selecting the mode of operation
1. Use the keys or to navigate to the field
Sequence (3).
2. Press the key .
3. Use the key to change operating mode.
The arrows between the buttonhole shapes appear
or
disappear as appropriate.
4. Confirm the selection with the key .
8.1.4 Adjusting the cutting length
On the display, the field (1) indicates the cutting length. You can
adjust the cutting length.
