Software settings
Operating Instructions 581 - 00.0 - 02/201592
To select a pre-programmed buttonhole:
Step
1. Using the key , navigate to the field Buttonhole
number (3).
2. Press the key .
The cursor flashes.
3. Select the desired buttonhole number using the
keys or .
As a selection aid, the current buttonhole shape (1) and the
most important corresponding values (2) are displayed.
4. Confirm the selection with the key .
8.1.3 Sequential mode
Depending on the setting, the machine will be in either automatic,
manual or light barrier mode ( 4.2.2 Modes of operation, p. 31).
In sequential mode you can switch between programmed button-
holes in the sequence at any time, unless you are working in light
barrier mode.
There are 2 steps for selecting a buttonhole in sequential mode:
Sequence
1. Select a sequential number.
2. Select a buttonhole.
