Setup
Operating Instructions 581 - 00.0 - 02/2015 87
Abb. 57: Lubricating (3)
7.16 Topping up the oil
To top up the oil reservoirs, use only an oil with the same speci-
fications as that for lubricating ( 7.15 Lubrication, p. 84).
To top up the oil reservoirs:
Step
1. Top up the oil reservoir (2) through the fill opening (1) up to the
max mark.
(6) - Spreader plate (7) - Spreader
⑥
⑦
