Setup
Operating Instructions 581 - 00.0 - 02/201584
To set the operating pressure:
Step
1. Pull the pressure controller (1) up.
2. Turn the pressure controller (1) such that the pressure
gauge
(2) displays the correct operating pressure:
• Turn clockwise = increases pressure
• Turn counter-clockwise = reduces pressure
3. Push the pressure controller (1) down.
7.15 Lubrication
The wicks, felt, looper and needle bar must all be lubricated
with a little oil when setting up the machine, or after longer stand-
still periods.
All moving parts in the machine are lubricated via an oil-wick
system from 2
oil reservoirs.
Use only DA 10 lubricant or an equivalent oil conforming to the
following specifications for lubrication:
NOTICE
Material damage from incorrect operating pressure!
Incorrect pressure can cause damage to the machine.
Ensure an operating pressure of 6 ± 0.5 bar.
ATTENTION
Risk of environmental damage from oil!
Oil is a pollutant and must not enter the
wastewater system or the ground.
Collect waste oil carefully.
Dispose of waste oil and oily machine parts
in accordance with the applicable statutory
regulations.
